Hanwha - WWT-P-5403L - Wisenet WAVE Client Workstation (Linux OS)
Part number:
WWT-P-5403L
Price:
Wisenet WAVE Client Workstation (Linux OS)
Features:
- Preloaded and configured with Wisenet WAVE video management system
- Supports Wisenet and ONVIF conformant IP cameras
- Latest 13th Generation Intel Core i5 CPU
- Nvidia Quadro T400 w/ (3) mDP Output
- 3x mDP to HDMI adapters included
- Built-in HDMI/DP/VGA output
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Powered by the Ubuntu 20.04 LTS Operating System
| SYSTEM | |
| Video Management Software | Wisenet WAVE |
| OS Drive Bays | 1 x 256GB SSD (internally mounted) |
| Network Interface | 1 x RJ-45, Gigabit Ethernet |
| Processor | 1 x Intel® Core™ i5 13th Generation |
| Memory | 16GB DDR4 |
| Operating System | Windows 10 IoT Enterprise / Ubuntu Linux 20.04 LTS |
| Video Outputs | Nvidia Quadro T400 GPU, 3x mDP with 3x HDMI adapters |
| USB Ports | Rear: (4) USB 3.2 Gen 1, (2) USB 2.0; Front: (2) USB 3.2 , (2) USB 2.0 |
| Other Ports | 3.5mm audio output |
| Keyboard & Mouse | Included |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL |
| Mechanical | Form Factor | Small Form Factor Workstation |
| Color / Material | Black / Metal & Plastic | |
| Dimensions (WxDxH) | 3.65" x 11.53" x 11.42" (92.6mm x 292.8mm x 290mm) | |
| Weight | 11.38 lbs (5.16 kg) | |
| Electrical | Power Supply | 1 x 300W 80 Plus Platinum |
| Power Input | 100 ~ 240V AC | |
| Power Consumption | Maximum 300W | |
| Environmental | Operating Temperature | 41°F ~ 95°F (5°C ~ 35°C ) |
| Storage Temperature | -40°F ~ 149°F (-40°C ~ 65°C ) | |
| Operating Humidity | 20% to 80% relative humidity (non-condensing) | |
| Certification | UL, cUL, CB, FCC, 80 Plus Platinum | |
