AV8576DN-28 - 8MP Low-Profile Multi-Sensor Versatility - IDIS
Part number:
Price:
- • 8MP Resolution
- • Fixed Lenses 2.8mm(x4)
- • Day and night (ICR)
- • True wide dynamic range (WDR)
- • IK10 / IP66
- • PoE (IEEE 802.3af Class 3)
- • Two-way audio
- • Alarm in / out
- • Supports ONVIF
- • Easy 3-axis camera adjustment
- • NDAA Compliant
| Camera | |
|---|---|
| Image Sensor (CMOS) | 8MP (1080p x 4) CMOS Progressive Sensor |
| Optical Format | 1/2.8" |
| Pixel Pitch | $2.0\mu\text{m}$ |
| Minimum Illumination (Color (Day Mode)) | 0.15 Lux |
| Minimum Illumination (B/W (Night Mode)) | 0.15 Lux |
| Full FOV Resolution (Total) | 7680 H x 1080 V |
| Full FOV Resolution (Per Sensor) | 1920 H x 1080 V |
| Dynamic Range | Up to 100dB |
| Frame Rates (At Max Resolution) | 30fps (8MP) |
| Frame Rates (Multi-Stream) | Up to 30fps (8MP) + 30fps (8MP) + 30fps (0.9MP) |
| Lens (x4) | 2.8mm, 1/2.7", F1.6, H-FOV = 98° |
| Programmability | |
| Optics | M12 lens and remote focus module |
| Low-Light Performance | NightView technology |
| Programmable Shutter Speed | Auto/manual 0.1ms ~ 500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| Backlight Compensation | Auto |
| White Balance Mode | Auto/manual |
| Gain Control | Auto |
| Flicker Control | 5Hz–255Hz adjustable |
| Scaling (8MP) | 1920x1080, 1280x720, 960x540, 640x360 |
| Scaling (20MP) | 2592x1944, 2560x1440, 2304x1296, 2048x1536, 1920x1080, 1600x1200, 1296x972, 1280x960, 1280x720, 800x600, 640x480 |
| Wide Dynamic Range | Adjustment between WDR and LDR modes |
| Efficiency | SNAPstream+ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control |
| Miscellaneous | Programmable brightness, contrast, sharpness, saturation, hue |
| Password | 16-digit ASCII character password |
| On-Screen Display (OSD) | Time/date/camera name/custom text |
| Data | |
| Compression Type | H.265/H.264 (MPEG-4, Part 10)/Motion JPEG 21 levels of quality |
| Bit Rate Control | 128K–8000K |
| Smart Codec | Smart GOP |
| Network Protocols | SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, QoS, DDNS, Zero Configure |
| Network Interface | 10/100/1000Mbps Ethernet, RJ45 |
| Max Camera Bandwidth | 36Mbps (9Mbps per sensor) |
| Multi-Streaming | 2 x H.265/H.264 stream, 1 x M-JPEG stream (per sensor) |
| Users | Live Viewing/Administrator for up to 10 clients |
| Event | |
| Event Trigger | Motion detection, tampering detection, alarm in |
| Notifications | Send a message via e-mail/FTP/NAS, SD Card Recording, Record JPG/MP4 |
| Compliance | |
| Industry Standard | ONVIF Profile S, G, and T conformant |
| Listings | UL60950-1, E489591 |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55032 Class A, EN55035, EN61000-3-2, EN61000-3-3 |
| Mechanical | IK-10 (EN62262), IP66 (EN60529) |
| Environmental | |
| Operating Temperature | -40°C (-40°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Electrical | |
| Alarm Input/Output | 1 input (wet contact)/1 output (wet contact) |
| Power Over Ethernet | IEEE 802.3at (PoE+), Class 4 |
| Auxiliary Power | 12-48V DC, 24V AC |
| Power Consumption | 14W max |
| Audio | |
| Streaming | Two-way |
| Compression | G.711 PCM 8 kHz/8 bit |
| Input/Output | Line in/ Line output |
| Mechanical | |
| Casing | Die-cast aluminum chassis with polycarbonate dome bubble IP66 weather proof standard Impact resistant, IK-10 rated |
| Gimbal | Easily adjustable, 3-axis w/360° pan, 90° tilt, and 360° z-axis |
| Dimensions (Unit) | Ø 7.7" (196mm) x 3.1" H (78.5mm) |
| Dimensions (Bubble Only) | Ø 6.7" (169.2mm) x 1.3" H (33.4mm) |
| Dimensions (Packaged) | 8" W (203mm) x 8" L (203mm) x 4" H (102mm) |
| Weight (Unit) | 3.8lbs (1.7kg) |
| Weight (Packaged) | 4.4lbs (2.0kg) |
| On Board Storage | MicroSDXC slot up to 1TB (card not included) |
| Body Color | AV Costar White (Pantone® Cool Gray 1C) |
Name
Description
Size
Downloads
File
AV8576DN-28_Datasheet.pdf
0.7mb
This is a low-profile multi-sensor camera housing four independent 2.1MP sensors for a total composite resolution of 7680 x 1080 (8MP). Each sensor uses a 1/2.8" CMOS with a fixed 2.8mm (F1.6) M12-mount lens providing a 98-degree horizontal field of view per sensor. The camera does not have integrated IR illumination. It supports video compression in H.265, H.264, and MJPEG formats, with streams managed independently per sensor. The camera includes up to 100dB WDR, day/night operation, and remote focus adjustment. It is housed in an IK-10 and IP66-rated die-cast aluminum casing. It operates on PoE+ (802.3at) or 12-48V DC/24V AC, with max consumption of 14W, and within a temperature range of -40°C to +50°C (-40°F to 122°F).
