CBI5D13IFHE - 5 MP DirectNET Bullet with AI - IDIS
Part number:
Price:
• DirectNET™ Network 5 Megapixel Bullet Camera with AI
• 5MP
• 1/2.8″ CMOS
• 2.7 -13.5mm Motorized Varifocal
• Remote Focus and Zoom
• 6 IR LEDs
• 131.2ft (40m) range
• True Day/Night
• T-WDR
• Outdoor
• Vandal
• IP67 and IK10 Rated
• Heater
• On-Camera Analytics
• 12VDC and PoE
| Model Information | |
|---|---|
| Model | CBI5D13IFHE |
| Image Sensor | Sony IMX335 CMOS Progressive Sensor |
| Optical Format | 1/2.8" |
| Video Specifications | |
| Minimum Illumination | Color (Day Mode): 0.15 Lux @ F1.4 B/W (Night Mode): 0 Lux (IR LED On) |
| Full FOV Resolution | 2592 H x 1944 V |
| Scaling | Yes |
| IR Illumination | Yes |
| Dynamic Range | 120dB (True WDR) |
| Frame Rates | Single Stream Up to 30fps (5MP) |
| Lens | DC Iris 2.7-13.5mm, F1.4-F3.2, H-FOV = 30.4°–101.2°, V-FOV = 22.8°–72.5°, D-FOV = 38°–137.4°, IR Corrected |
| Programmability Optics | Motorized Vari-focal |
| S/N Ratio | More than 45dB |
| Electronic Shutter Speed | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Privacy Masking | 8 Zones |
| Mirroring / Pivot | Horizontal / Vertical / Pivot |
| Scaling Resolutions | 4:3: 2592x1944, 1920x1440, 1280x960x 640x480 16:9: 2592x1456, 1920x1080, 1280x720, 640x360 |
| Wide Dynamic Range | 120dB True WDR |
| Image Settings | Exposure, White Balance, Self-Adjusting Video Mode (Sharpness, Contrast, Colors, Brightness Control) |
| Defog | Supported |
| Intelligent Video | Video Motion Detection, Active Tampering Alarm, Object Detection, Intrusion, Loitering, Line Crossing, Face Detection |
| On-Screen Display (OSD) | Date / Time / Custom Text |
| Data Transmission | |
| Compression Type | H.265, H.264 (MP), Motion JPEG |
| Compression Level | Basic, Standard, High, Very High |
| Bit Rate Control | Constant Bitrate / Variable Bitrate |
| Recording Session Buffer (NLTSrec) | Yes (Up to 60MB) |
| Intelligent Codec | Supported |
| Motion Adaptive Transmission (MAT) | Off / On |
| Transmission Protocols | DirectNET 2.0 Protocol, IPv4, IPv6, RTP |
Name
Description
Size
Downloads
File
CSV_CBI5D13IFHE_001_ENG.pdf
0.4mb
The CBI5D13IFHE is a 5MP bullet camera with a 1/2.8” CMOS sensor and a 2.7-13.5mm motorized vari-focal lens. It provides IR illumination up to 40 meters, uses H.265, H.264, and M-JPEG compression, and includes on-camera analytics and True Wide Dynamic Range. The housing is rated IP67 with a heater and IK10 for vandal resistance. It operates on PoE or 12VDC power and is NDAA compliant.
