CCC3520ATM - Resolution WDR Mini Box Camera - IDIS
Part number:
Price:
- • 690 HTVL-E resolution Image Sensor:
- • 1/3" PIXIM WDR Seawolf technology
- • Day/Night function with color signal control
- • Back Light Compensation (BLC)
- • Wide Dynamic Range (WDR)
- • Lens not included
- • Use Costar Video's recommended 2.5-6 mm
- • Super Wide DC Auto Iris lens for wide angle views
- • Power requirements: DC12V or AC24V
| General Information | |
| ADI Part Number | CI-CCC3520AT |
| Brand Name | Costar Video Systems |
| Manufacturer | Costar Video Systems, LLC |
| Manufacturer Part Number | CCC3520ATM |
| Product Model | CCC3525NWD |
| Product Name | 690 HTVL-E Resolution WDR Mini Box Camera |
| Product Type | Surveillance Camera |
| Technical Information | |
| Connectivity Technology | Wired |
| Lens Type | Varifocal |
| Minimum Focal Length | 2.8mm |
| Optical Zoom | 4.3x |
| Camera | |
| Image Sensor Type | Pixim |
| Wide Dynamic Range | Yes |
| Environmental | |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -4°F (-20°C) |
| Lens | |
| Focal Length | 12mm |
| Lens Included | Yes |
| Maximum Focal Length | 12mm |
| Network & Communication | |
| Remote Management | No |
| Others | |
| ADI Part Number Replaces | CI-CCT2100KT |
| Model Number Replaces | CCT2100KIT |
| Physical Characteristics | |
| Color | Black, White |
| Depth | 2.8" |
| Height | 1.6" |
| Weight | 4.48oz |
| Width | 1.6" |
| Power Description | |
| Input Voltage | 12V DC, 24V AC |
| Product Information | |
| Mount Type | Box Mount, Ceiling Mount, Wall Mount |
| Storage | |
| Recording Formats | Full HD |
| Video | |
| Analog Video Signal Format | CVBS |
| Miscellaneous | |
| Country of Origin | KR |
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Digital Noise Reduction, Privacy Masking, Wide Dynamic Range |
| Indoor/Outdoor | Indoor, Outdoor |
Name
Description
Size
Downloads
File
CI-CCC3520AT_ProductManual.pdf
0.7mb
The CCC3520ATM is an analog surveillance camera with a Pixim image sensor supporting 690 TVL-E resolution and wide dynamic range. It uses a 2.8-12mm varifocal lens with 4.3x optical zoom. It operates from -20°C to +50°C and can be powered by 12VDC or 24VAC. The camera features auto gain control, automatic white balance, backlight compensation, digital noise reduction, and privacy masking. It is suitable for indoor or outdoor installation.
