CDI4H36IW - 4MP CentralNET Indoor Fixed Lens Dome - IDIS
- • 4 Mega Pixel Resolution
- • Smart Codec
- • Intelligent Video Motion Detection, Intrusion Detector
- • Quad Stream(H.264/H.265, MJPEG)
- • Onvif Profile S and T
- • Easy Install : Zero Configuration, Discovery, PoE
- • Multi User Authority, IP Filtering, HTTPS, SSL
- • Cross Web Browsing(IE, Safari, Firefox, Chrome)
- • SmartManager
- • Central Point VMS
- • Central Point Mobile Android™ iOS™
| Model | CDI4H36IW |
| Lens & Image | |
| Lens | 3.6mm, F2.0 |
| Angle of View | 33°(H), 18° (V), 37° (D) |
| Image Sensor Type | 1/3” CMOS Sensor |
| Pixels | 2688(H)x1520(V) |
| Performance | |
| Min. Illumination | Color : 0.23Lux@F2.0 / BW : 0Lux@F2.0( IR On) |
| Scanning Mode | Progressive Scan |
| Noise Reduction | 2DNR, 3DNR |
| Digital Zoom | Yes(ROI) |
| Exposure Control | Auto |
| White Balance Control | Auto, Incandescent, Fluorescent, Outdoor, Manual |
| Image Effect | Flip, Mirror, Defog |
| Flicker Free Mode | 50Hz, 60Hz |
| Shutter Speed | Auto(1/10,000~1sec), Manual |
| IR Illuminator | 28 IR LEDs |
| Quantity | Up to 82ft |
| Wide Dynamic Range | True WDR 120db |
| Day and Night Mode | True D/N(Auto, Day, Night) |
| Video & Compression | |
| Compression | H.264/H.265(Baseline, Main, High Profile), MJPEG |
| Bitrate Control | CBR, CVBR (Max Bitrate: 10Mbps) |
| Resolution | 2592x1520, 2560x1440, 1920x1080, 1440x1080, 1280x1024 1024x768, 800x600, 640x480, 400x240, 320x240 |
| Streaming | Quad Stream : H.264/H.265x3, MJPEGx1 |
| Frame Rate | Max. 30fps |
| Audio | |
| Audio Compression | G.711 |
| Audio Streaming | 2 Way |
| Audio | 1 Input, 1 Output(Terminal Block) |
| Event & Detection | |
| Motion Detection Area | 16 Programmable Area(Include Area 8, Exclude Area 8) |
| Privacy Mask Zone | 8 Programmable Zone |
| Video Contents Analytics | Tampering, Motion Detection, Intrusion Detector |
| FTP Uploading | MJPEG |
| Event Notification | E-mail, FTP, Notification Server, XML Notification, Audio Alert |
| Manual Trigger | 4 Programmable Trigger |
| Event Buffering FTP | Pre : 10sec, Post : 60sec |
| Audio Alert | User Defined 3 Audio File |
| Storage & Network | |
| Micro SD Type | SDHC, SDXC,(Class 10,128GB Max) |
| Micro SD Recording Mode | Event, Continuous |
| Protocol | TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, QoS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour |
| Camera Protocol | Onvif S and T |
| Ethernet | RJ-45(10/100Base-T) |
| Max. User Connection | Live : 10 Users, Playback : 3 Users |
| System & Security | |
| Login Authority | Administrator, Operator, Guest |
| Security | Multi User Authority, IP Filtering, HTTPS, SSL |
| Client Software | Web, SmartManager, Client S/W, Mobile S/W |
| Mobile Support | Android, iOS |
| Web Browsing | IE, Chrome, Safari, Firefox |
| Software Reset | Restart, Reset, Factory Default |
| Network Time Sync | NTP Server, Synchronized Computer, Manual |
| Remote Upgrade | --- |
| Physical & Environmental | |
| Composite Out | Yes |
| Alarm | 1 Input, 1 Output(Terminal Block) |
| Operating Temperature | 14°F ~ 104°F (-10°~+40ºC) |
| Operating Humidity | 0~90% RH(Non-Condensing) |
| Power Source | PoE(IEEE802.3af Compliance, Class0)/12VDC |
| Power Consumption | 180mA(7.6W)@PoE ~ 680mA(7.4W)@12VDC |
| Dimension | 5.12”(Ø)x3.70”(H)in |
| Net Weight | 0.84lbs |
| Approvals | FCC, CE, KC |
This is a 4-megapixel indoor dome camera from IDIS's CentralNET series. It features a 1/3-inch CMOS sensor and a fixed 3.6mm F2.0 lens, providing a standard 33-degree horizontal field of view. It outputs video at a maximum resolution of 2688 x 1520.
For operation in low light, it incorporates 28 infrared LEDs with an effective range of 25 meters (82 ft). Its imaging features include 120 dB True Wide Dynamic Range (WDR), 2D/3D Digital Noise Reduction (DNR), and digital defog. It supports two-way audio with audio I/O and provides one alarm input and output. It utilizes modern H.265 and H.264 compression, quadruple video streaming, and local storage via a Micro SD card slot (up to 128GB). It supports standard ONVIF Profile S and T for third-party integration. The camera is designed for indoor use within a temperature range of -10°C to 40°C and can be powered via PoE (802.3af) or 12V DC, with a typical power consumption under 7.6 watts.
