- • SIP(VoIP) Supports
- • Clear Voice Communication with Echo Cancellation
- • IR LED (Distance : 5m / 16ft)
- • IK10 / IP66 / NEMA4X support
| Video | |
| Image Sensor | 1/2.8" CMOS |
| Max. Resolution | 1920 x 1080 |
| Scanning Mode | Progressive Scan |
| Lens Type | Fixed-focal |
| Focal Length | 1.85mm |
| Aperture | F2.3 |
| Iris Control | Fixed Iris |
| Angular Field of View | 180º(H) |
| Min. Illumination | COLOR : 0.1 lux @ F2.3 B/W : 0 lux (IR LED ON) |
| Dynamic Range | 120dB (True WDR) |
| Electronic Shutter Speed | Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (1/7.5, 1/15) |
| Day and Night | Yes (ICR) |
| IR Distance (LEDs) | 5m / 16ft (1ea) |
| Image Setting | Exposure, White Balance, Self-Adjusting Video Mode(Sharpness, Contrast, Colors, Brightness Control) |
| Backlight Compensation | - |
| Mirroring / Pivot | Horizontal / Vertical |
| Image Stabilizer | - |
| De-fog | Yes |
| Privacy Masking | 8 Zones |
| Intelligent Video | Video Motion Detection, Active Tampering Alarm, Trip Zone |
| Video Out | - |
| Network | |
| Video Compression | H.265, H.264 (MP), M-JPEG |
| Intelligent Codec | Yes |
| Bitrate Control | H.265 - CBR / VBR, H.264 - CBR / VBR |
| Audio Compression | G.726, G.711 u-Law, G.711 a-Law, G.722 |
| Two-way Audio | Yes |
| IP Camera Protocol | DirectIP 2.0, ONVIF Profile S/T |
| Max. Frame Rate | 30ips : 1920 x 1080 (WDR) |
| Supported Resolution | 1920x1080, 1280x720, 640x360, 352x240 |
| Multi-video Streaming | Quadruple Streaming |
| Network Protocols | DirectIP 2.0 Protocol, IPv4, IPv6, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, uPNP, SNMPv2, SIP |
| Security | Digest authentication, Password Protection, User access log, IP Filtering, IEEE802.1x(EAP-TLS), Chained Fingerprint, SSL Encryption, HTTPS Encryption |
| Ethernet | RJ45 (10/100BASE-T) |
| Recording Session Buffer (NLTSrec) | Yes (Up to 60MB) |
| Edge Storage | micro SD/SDHC/SDXC, Smart Failover (Up to 512GB) |
| Alarm and Event | |
| Trigger Event | Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone |
| Event Notification | Remote S/W, Email (with Image) |
| Audio Alarm | Yes |
| Audio In / Out | 1 (Built In MIC with Echo Cancellation) / 1 (Built In SPK) |
| Alarm In / Out | 1 / 2 |
| Environmental | |
| Vandal Proof Casing | IK10 |
| Outdoor Ready | IP66, NEMA4X |
| Operating Temperature | -30°C ~ +55°C (-22°F ~ +131°F) *Starting up at above 0°C (32°F) |
| Operating Humidity | 0% ~ 90% |
| Electrical | |
| Power Source | 12VDC, PoE IEEE 802.3af (Class 3) |
| Power Consumption | 12V=, 1.87A, 22.4W PoE, (IEEE 802.3af Class 3), 9.5W (DC Output : 12V=, 1A MAX with Adaptor) |
| Approval | FCC, CE, KC |
| Mechanical | |
| Dimensions | 52mm x 165mm x 46mm (2.05" x 6.50" x 1.81") |
| Weight | 0.52 kg (1.15lb) |
This is a Full HD (1920x1080) 180-degree panoramic network camera with a fisheye lens, designed to provide a single, wide-angle view. It uses a 1/2.8-inch CMOS sensor paired with an ultra-wide 1.85mm fixed-focal lens at F2.3 to achieve its 180-degree horizontal field of view. For low-light performance, it includes a single IR LED with a 5-meter illumination range. It features 120dB True Wide Dynamic Range and defog capability. The camera supports modern H.265 and H.264 video compression and delivers up to 30 frames per second at full resolution.
Housed in a robust IP66, NEMA4X, and IK10-rated enclosure, it is built for demanding outdoor and industrial environments. It operates in temperatures from -30°C to +55°C. It can be powered by 12VDC or PoE 802.3af, with a maximum consumption of 22.4 watts. The unit includes a built-in microphone and speaker for two-way audio, supports edge storage via microSD card, and integrates via ONVIF Profile S/T and DirectIP 2.0.
