ILLUSTRA - IP5M-15PNT - 5 Megapixel x 3 Network IP Illustra Panoramic Multisensor Camera with 2.99mm Lens
Part number:
Price:
Product Overview
The Illustra IP5M-15PNT is a 15MP-class panoramic multisensor network camera combining three 5MP sensors into a single stitched view. Its 188° horizontal coverage, adaptive IR illumination, edge AI analytics, and rugged outdoor housing provide comprehensive surveillance with reduced blind spots.
Key Configuration
Model: IP5M-15PNT | Resolution: 14.47MP stitched output (3×5MP sensors) | Lens: 2.99mm fixed, F2.0 | Field of View: 188° horizontal | Frame Rate: 30/25fps | IR Distance: Up to 20m | Storage: microSDXC up to 2TB | Power: PoE+ or 24VAC
Key Features
- · Three Sony 1/2.8-inch progressive-scan RGB CMOS sensors
- · 14.47MP panoramic resolution up to 5952×2432 at 30/25fps
- · 188° horizontal field of view for expansive area coverage
- · True Day/Night operation with automatic IR-cut filter
- · 850nm adaptive IR illumination up to 20m (65.6ft)
- · H.264, H.265, MJPEG, and IntelliZip smart compression
- · AI object classification, face detection, tamper detection, and audio event detection
- · Supports object, perimeter, direction, dwell, queue, crowd, enter, and exit rules
- · Encrypted microSD recording, TrickleStor offline recording, and backfilling
- · IP66/IP67, NEMA 250 Type 4X, and IK10-rated housing with dual power support
Technical Context
The camera stitches three sensor views into one panoramic image, allowing broad-area monitoring from a single device. IntelliZip compression, multiple streams, edge analytics, and onboard storage help reduce network and recording infrastructure requirements.
Installation Notes
Mount the camera on a suitable surface with an unobstructed panoramic view. Provide PoE+ or 24VAC power, connect the Gigabit Ethernet interface, and configure the desired analytics and microSD recording functions; operate within -40°C to 60°C with non-condensing humidity up to 90%.
| Product Information | |
| Model | IP5M-15PNT |
| Product Type | Illustra 15MP panoramic multisensor network camera |
| Sensor Configuration | 5MP × 3 Sony 1/2.8" progressive-scan RGB CMOS sensors |
| Panoramic Image | Three-sensor stitched panoramic view |
| Product Features | Fixed lens, true day/night, adaptive IR, AI analytics, IntelliZip smart codec and dual power supply |
| Camera and Optics | |
| Maximum Resolution | 5952 × 2432, 14.47MP |
| Lens | 2.99mm fixed lens |
| Aperture | F2.0 |
| Horizontal Field of View | 188° |
| Vertical Field of View | 74° |
| Camera Angle Adjustment | Pan: 0° to 370° Tilt: 0° to 60° Roll: ±5° |
| Day/Night | True day/night with automatic IR-cut filter |
| Minimum Illumination | Color: 0.09 Lux at 1/30s, 0.01 Lux at 1/4s Black and white: 0.04 Lux at 1/30s, 0.001 Lux at 1/4s |
| Exposure Range | 1/4s to 1/32000s |
| Infrared Illumination | |
| IR Wavelength | 850nm |
| IR Technology | Adaptive IR and Smart IR |
| IR Distance | Up to 20m (65.6ft) |
| Video | |
| Video Compression | H.264, H.265 and Motion JPEG |
| Frame Rate | 14.47MP at 30/25fps |
| Video Streaming | 4 streams; up to 5 concurrent shared streams |
| Smart Codec | Illustra IntelliZip smart compression for reduced bandwidth and storage requirements |
| Bit Rate Control | CBR, VBR and CVBR |
| ROI | Multiple ROI areas, including AI ROI |
| WDR | True multi-shutter WDR up to 120dB, Smart WDR, TWDR 2x and TWDR 3x |
| Image Enhancement | SmartDefog, auto exposure, auto white balance, auto gain control, flickerless mode, text overlay and electronic image stabilization |
| Noise Reduction | 2D and 3D digital noise reduction |
| Privacy Zones | Up to 10 user-definable rectangular zones |
| Video Output | 1 × Micro HDMI for outdoor preview or indoor PVM |
| Video Analytics | |
| AI Object Classification | Person, bicycle, bus, car, motorbike, train, truck, cart, backpack, handbag and suitcase |
| Object Attributes | Person clothing colors and vehicle colors |
| Analytics Rules | Object detected, perimeter, linger, dwell, abandoned object, removed object, enter, exit, crowd, queue, direction and tripwire |
| AI Functions | Face detection, tamper detection, blur detection, metadata, smart search and motion detection |
| AI Audio Detection | Loud abnormal sound, glass break, fire/smoke alarm and low-pitch sound detection |
| Person Counting | Supported with future firmware release |
| Person and Face Redaction | Supported with future firmware release |
| Audio and Alarm | |
| Audio Compression | G.711 μ-law, 9kHz/16-bit |
| Audio Input | Built-in microphone and 1 × line input |
| Audio Output | 1 × line output |
| Audio Communication | Bi-directional, full-duplex audio |
| Alarm I/O | 1 alarm input and 1 alarm output |
| Event Triggers | Motion detection, tamper detection, face detection, AI object classification, alarm input and network loss |
| Event Actions | SD recording, snapshots, SMTP email, FTP transfer, CIFS, auxiliary output, audio clip playback and SIP |
| Network and Security | |
| Ethernet | 1 × RJ45 10/100/1000Mbps auto-sensing Ethernet port |
| Network Protocols | ARP, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, RTSP, RTCP, RTP, SMTP, SNMPv1/2c/3, TCP/IP, TLS, UDP, UPnP, Bonjour, DDNS, LDAP, PPPoE, SFTP, LLDP, unicast and multicast |
| ONVIF | Profiles S, G, T and M |
| SNMP | SNMPv2c and SNMPv3 |
| Cybersecurity | Secure boot, signed and encrypted firmware, TLS/HTTPS, WS-Security, certificate management, TPM 2.0, IP filtering, IEEE 802.1x, PEAP, EAP-TLS, multi-level password protection and user access logs |
| Simultaneous Users | Up to 10 |
| Network Management | Supported |
| System Integration | Illustra iAPI through Connected Partner program |
| Storage and Peripherals | |
| Onboard Storage | 1 × MicroSDXC slot, Class 10 or higher, up to 2TB; card not included |
| Event Buffering | 1 to 10 seconds pre-event and post-event buffering |
| Storage Security | Encrypted storage and streaming |
| Offline Recording | TrickleStor offline recording and encrypted backfilling |
| Wireless Configuration | Micro USB connection through optional IA-KIT-WD-UUA USB Wi-Fi dongle |
| Power | |
| Power Supply | IEEE 802.3at Class 4 PoE+, 0.53A / 25.62W 24VAC ±10%, 2.5A / 27W via 3.5mm 2-pin terminal block |
| Dual Power Supply | Supported; PoE+ and 24VAC |
| Power Consumption | PoE+: 25.62W 24VAC: 27W |
| Surge Protection | 6kV contact discharge, 8kV air discharge |
| Mechanical and Environmental | |
| Housing | Aluminum alloy housing with polycarbonate trim and clear dome cover |
| Color | Signal White, RAL 9003 |
| Protection Rating | IP66/IP67, NEMA 250 Type 4X and IK10 |
| Dimensions | Ø195 × 157mm (Ø7.68" × 6.18") |
| Weight | Net: 1.1kg (2.42lb) Gross: 2.8kg (6.17lb) |
| Operating Temperature | -40°C to 60°C (-40°F to 140°F); IR off above 50°C |
| Start-up Temperature | -40°C (-40°F) |
| Humidity | Up to 90% RH, non-condensing |
| Certifications and Support | |
| Compliance | NDAA compliant and TAA compliant |
| Certifications | FCC, CE, UL, CB, RoHS, WEEE and REACH |
| Supported Browsers | Microsoft Edge, Firefox, Safari and Chrome |
| Supported Tools | Illustra Connect for Windows and Illustra Tools for iOS/Android |
| Warranty | 5 years |
