Vivotek - SFP-1000-SM13-10I - Industrial Gigabit Mini GBIC Single Mode 1312nm 10KM, LC Con
Part number:
SFP-1000-SM13-10I
Price:
Industrial Gigabit Mini GBIC Single Mode 1312nm 10KM, LC Connector.
Features:
- Data Rate Gigabit 1.25G
- Type SFP
- Center Wave Length 1310 nm
- Laser Type Fabry-Perot
- Tx -3 ~ -9 dBm
- Rx -3 ~ -21 dBm
- Voltage 3.3V
- Transmission Range 9/125μm, up to 10km
- Fiber Type (MMF/SMF) SMF
- Connector LC
- Dimensions (L x W x H) 55.9 x 14.69 x 12.39 mm
- Operating Temperature -40°C ~ 85°C (-40°F ~ 185°F)
- Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
- Humidity 5 ~ 90% (non-condensing)
- MSA Compliant Yes
- Certifications IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11
| Data Rate | 1.25G |
| Wave Length | 1310 nm |
| Laser Type | Fabry-Perot |
| Tx(dBm) | -3 ~ -9 dBm |
| Rx(dBm) | -3 ~ -21 dBm |
| Voltage | 3.3V |
| Transmission Range | 9/125μm, up to 10km |
| Fiber Type (MMF/SMF) | SMF |
| DDM (Digital Diagnostics Monitoring) | Yes |
| Connector | LC |
| Dimensions (L x W x H) | 55.9 x 14.69 x 12.39 mm |
| Operating Temperature | -40XC ~ 85XC (-40XF ~ 185XF) |
| Storage Temperature | -40XC ~ 85XC (-40XF ~ 185XF) |
| Humidity | 5 ~ 90% (non-condensing) |
| MSA Compliant | Yes |
| Certifications | IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11 |
