Hanwha - SPA-B1000 - IP Audio Bridge, Background Music, Analog Audio Input (L, R : +6dBV Max line IN level), 1GB Internal Storage, Single Micro SD slot (Up to 32GB), Built in Relay, SUNAPI, PoE
Part number:
SPA-B1000
Price:
IP Audio Bridge, Background Music, Analog Audio Input (L, R : +6dBV Max line IN level), 1GB Internal Storage, Single Micro SD slot (Up to 32GB), Built in Relay, SUNAPI, PoE
Features:
- IP Audio Bridge
- Background Music
- Analog Audio Input (L, R : +6dBV Max line IN level
- 1GB Internal Storage
- Single Micro SD slot (Up to 32GB)
- Built in Relay
- SUNAPI
- PoE
| Product | |
| Type | IP Audio Bridge |
| Line Input | |
| Maximum Input Level | L, R : +6dBV Max |
| Network | |
| Ethernet | 10 /100 Base-T |
| Memory | |
| Internal Memory | 1 GBytes |
| External Memory (Micro SD) | SDHC upto 32GB (SANDISK) |
| Contact | |
| Contact Input. Dry contact | One channel |
| Contact Output. Dry contact (NO) | One channel |
| General | |
| Operating Temperature | -20 ~ +50℃ (-4°F ~ +122°F ) |
| Operating Humidity | 10 ~95% RH (Non-Condensing ) |
| Weight | 0.24 Kg |
| Size | 123(W)*80(H)*30.6(D) mm |
| Color | White |
| Certificate | EMC : KS C 9832/9835, EN 55032/55035, FCC Part 15 Subpart B, ICES-003 Safety : KC 62368-1, UL 62368-1, CAN/CSA 62368-1 |
| Power | |
| PoE | PoE (IEEE 802.3 af type 1 Class 0), DC 24V |
| Audio | |
| Supported Audio Format | File Streaming: WAV, MP3 in mono/stereo from 64 kbps to 320 kbps. Sampling rate from 16 kHz up to 48 kHz |
| Network Protocol | |
| Security | Password protection : admin,setup,user,guest ( sha-2, Digest authentication, User access log ) Digest authentication, User access log |
| Supported Protocols | IPv4, HTTP, HTTPS, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP |
| System Integration | |
| API (Application Programming Interface) | SUNAPI |
| Event & Preset Virtual Contact, Dry contact | |
| Functional Monitoring | Connection verification, Built-in system logging |
