Jonard - UTSS-1641 - Medium Voltage Utility Cable Semicon Scoring Tool 16 - 41 mm
• Suitable for cables with diameters from Ø 16 - 41 mm and insulation thicknesses up to 2 mm
• Allows for longitudinal, helical, and circular cuts for versatility in stripping applications
• Functions similarly to a vice system, ensuring stability and accuracy during operation
• Fine-tune the blade depth from 0 to 0.9 mm (in 0.1 mm increments) using the easy-to-turn adjustment knob
• Stop clamp limits the stripping length for repeatable and uniform results
• Spring-loaded holding system ensures firm positioning and control by utilizing spring pressure for optimal grip
| Application | Non vulcanized, peelable semiconductive layer |
| Diameter Range | 0.63” - 1.61” (16 - 41 mm) |
| Insulation Thickness | 0” - 0.079” (0 - 2 mm) |
| Maximum Rotating Diameter | 5.12” (130 mm) |
| Dimensions | 5 in x 3 in x 1 in (12.7 cm x 7.62 cm x 2.54 cm) |
| Weight | 0.28 lb (127.12 g) |
Designed for precision and ease of use, the Jonard Tools Non-Vulcanised Semiconductive Layer Cable Stripper is the perfect tool for removing the peelable semiconductive layer from medium voltage (MV) cables. With the ability to perform longitudinal, helical and circular cuts, it ensures clean and accurate stripping while preserving the integrity of the underlying insulation.
