Luminys - LCE-LPR - LumiCenter LPR Search Channel (License)
• Read license plates using any camera
• Convert license plate characters into text
• Compare license plate against positive lists and negative lists
• Search license plate in stored video
• NDAA Compliant
• Identify vehicle by license plate
• Monitor parking and track vehicles using license plates
| Category | Specification |
| Region | Only license plates from North America (USA and Canada) can be read and recognized. |
| Operating System & Software | • Microsoft Windows 10 or Higher |
| • Microsoft Visual C++ 2015 Redistributable Package (x64) | |
| • NET Framework 4.5.2 | |
| RAM Usage | Minimum of 500 MB per camera (e.g., 16 cameras require 8 GB). |
| CPU | • Intel i7 or i9 latest generation, min. 3.0 GHz, must support AVX2. • One core per camera at 2MP resolution, plus two additional cores for the OS. |
| Camera (General) | • Minimum Resolution: 640 × 360 pixels • Optimal Resolution: 1280 × 720 • Minimum Frame Rate: 15 fps • Recommended Frame Rate: 25–30 fps • Auto-focus and zoom recommended. |
| Lighting | • Minimum required: 50 lux. • Stable operation not guaranteed with insufficient or excessive lighting. • Abrupt lighting changes may cause disruptions. |
| Scene & Camera Angle | • Position: Capture a single lane; dual-lane possible if centered. • Horizontal tilt from road ≤ 15°. |
| • Working Distance: 15–20 m (urban) / 20–30 m (high-speed). | |
| • Installation Height: 4–6 m above ground. | |
| • License plate bottom edge to horizon: 0° to 20°. • Avoid bends, speed bumps, junctions, etc. | |
| Image Tilt Limits | • X-Axis (Pitch): ± 35° • Y-Axis (Yaw): ± 40° • Z-Axis (Roll): ± 35° |
This add-on module enables the LumiCenter Plus and Max systems to recognise vehicle licence plates in real time from any surveillance camera. The system sends notification alerts (UI, text, email or API) when a licence plate from the positive or negative lists is detected. The module can also trigger actions, such as opening a gate or running a macro to automate tasks. It also allows you to search for licence plates in the archive. This add-on includes the LPR Search module (LCE-LPRS).
