Luminys - N9P-4RA2 - 2 x 4MP LumiFlex Dual-Sensor Dome Camera with 2.8 mm Lens, IR LEDs
Product Overview
Luminys N9P-4RA2 is a 2 x 4MP dual-sensor dome camera with two fixed 2.8mm lenses (F1.6), delivering 2688x1520 resolution per sensor at up to 20 fps. This dome camera features dual 1/2.7-in. CMOS sensors with 101° horizontal field of view per sensor, 120dB WDR, and 30.5m IR illumination with 8 IR LEDs (4 per sensor). The H.265/H.264 compression with two streams per sensor, IP67/IK10 ratings, and LumiFlex technology for flexible multi-sensor coverage.
Key Configuration
• Resolution: 2 × 4MP (2688 × 1520 per sensor) at up to 20fps
• Lens: Two fixed 2.8mm, F1.6, 101° H / 54° V / 120° D per sensor
• Power: PoE (IEEE802.3af) or 12VDC; max 13.0W / normal 4.8W
• Storage: MicroSD up to 256GB
Key Features
Dual 4MP CMOS sensors with 120dB WDR, 30.5m IR illumination, and H.265/H.264 compression. Supports intelligent motion detection with human/vehicle classification, line crossing, and intrusion analytics, built-in microphone, audio/alarm I/O, and ONVIF compatibility. Rated IP67 and IK10 for outdoor and vandal-resistant installations.
Technical Context
LumiFlex enables multi-sensor coverage from one camera housing with independently adjustable 4MP sensors and flexible separate or combined streaming. It includes 30.5m IR illumination and uses Intelligent Motion Detection (iMD) to distinguish human and vehicle activity while reducing false alarms.
Installation Notes
Dual-sensor dome camera with metal housing 164.0 × 84.0 × 69.4 mm, weighing 0.6 kg net. Built for outdoor use with operating from -40°C to 60°C. Supports 12VDC or PoE (IEEE802.3af) power and includes a built-in microphone with optional audio I/O.
| Camera | |
|---|---|
| Luminys Series | Specialty |
| Image Sensor | Dual 4MP 1/2.7-in. CMOS sensor |
| Maximum Resolution | 2688 × 1520 |
| Minimum Illumination | |
| Color | 0.0007 Lux at F1.6 |
| With IR Illumination On | 0 Lux |
| Illuminator | |
| Number of Illuminators | Eight (8) IR LEDs (Four (4) IR LEDs per Sensor) |
| Illuminator Control | Automatic, Manual |
| Maximum Illumination Distance | Up to 30.5 m (100.0 ft) |
| Electronic Shutter Speed | Automatic, Manual · 1/3 s to 1/100,000 s |
| S/N Ratio | > 56 dB |
| Lens | |
| Iris Type | Fixed |
| Lens Type | Fixed |
| Focal Length | 2.8 mm |
| Maximum Aperture | F1.6 |
| Close Focus Range | 1.1 m (3.6 ft) |
| DORI Distance | |
| Detect | 63.1 m (207.0 ft) |
| Observe | 25.0 m (82.0 ft) |
| Recognize | 12.5 m (41.0 ft) |
| Identify | 6.3 m (20.7 ft) |
| Video | |
| Compression | H.264, H.265, Smart Encoding H.265, Smart Encoding H.264, MJPEG (Sub Stream 1 Only) |
| Standard Codec Supported | H.265, H.264, MJPEG |
| Stream Capability | Two (2) Streams |
| Resolution | 4MP (2688 x 1520), 4MP (2560 x 1440), 3MP (2048 x 1536/2304 x 1296), 1080p (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D1 (704 x 480), VGA (640 x 480), CIF (352 x 240) |
| Maximum Frame Rate | Main Stream: 2688 x 1520 at 20 fps Sub Stream 1: D1 at 30 fps Sub Stream 2: 1080p at 30 fps |
| Video Bit Rate | H.264: 3 kbps to 10,240 kbps H.265: 3 kbps to 10,240 kbps |
| Bit Rate Control | CBR/VBR |
| Day/Night | Color, Black and White |
| Light Balancing | Wide Dynamic Range (120 dB) |
| Noise Reduction | 3D NR |
| Image Angle | 0°/90°/180°/270° |
| Mirror Rotation | Supported |
| Region of Interest | Four (4) Areas |
| Privacy Masking | Four (4) Areas |
| Analytics | |
| Intelligent Motion Detection | Supported with Alarms for Vehicles and Humans |
| Video Content Analytics | Line Crossing, Intrusion |
| Audio | |
| Compression | G.711a, G.711Mu, PCM |
| Interface | Input: Built-in Microphone and One (1) Channel Output: One (1) Channel |
| Alarm | |
| Event Triggers | Line Crossing, Intrusion, Motion Detection, iMD, Audio Detection, Video Tampering, Disk Full, Disk Error, Offline, IP conflict, Voltage Exception, Security Warning |
| Interface Input | One (1) Channel (3V-5VDC, 5 mA) |
| Interface Output | One (1) Channel (12 VDC, 300 mA) |
| Network | |
| Interface | RJ-45 (10/100 Base-T) |
| Protocol | IPv4, IPv6, DNS, TCP, UDP, DHCP, HTTP, HTTPS, 802.1x, RTSP, DDNS, P2P, SMTP, RTMP, PPPoE, UPnP, SNMP, Bonjour, QoS, Auto Registration, ICMP, IGMP, FTP, SFTP, RTP, RTCP, NTP, NFS |
| Interoperability | ONVIF (Profile S/G/T), CGI |
| Browser | Chrome, Firefox, Edge |
| Storage | FTP, SFTP, MicroSD Card (Max. 256 GB), NAS, Local Recording to PC |
| Electrical | |
| Power Supply | 12 VDC, PoE (802.3af) |
| Power Consumption | Maximum: 13.0 W Standard: 4.8 W |
| Construction | |
| Net Weight | 0.6 kg (1.4 lb) |
| Operating Temperature | -40 to 60 °C (-40 to 140 °F) |
| Storage Temperature | -40 to 60 °C (-40 to 140 °F) |
| Storage Humidity | < 95% RH (Non-Condensing) |
| Protection Ratings | IP67, IK10 |
| Product Dimensions | 164.0 mm x 84.0 mm x 69.4 mm (6.46 in. x 3.31 in. x 6.7 in.) |
| Packaging Dimensions | 205.0 mm x 121.0 mm x 101.0 mm (8.1 in. x 4.8 in. x 4.0 in.) |
| Material | Metal |
| Certifications and Compliance | |
| Certifications | FCC, IC |
| Compliance | NDAA |
