• Image Sensor: 1/2.8-in. Progressive Scan CMOS
• Max Resolution: 4MP
• Focal Length: 4x Optical Zoom
• Protection: IP66 (Weatherproof) and IK10 (Vandal-resistant).
• Operating Temp: –22 °F to +140 °F (–30 °C to +60 °C).
• Power: PoE (802.3af) or 12 VDC.
• Intelligent Motion Detection
• Video Content Analytics
| Image Sensor | 1/2.8-in. |
| Max. Resolution | 4MP (2560 x 1440) |
| Focal Length | 4x (2.8mm to 12mm) |
| Min. Illumination | Color: 0.006 lux at F1.6 B/W: 0.0006 lux at F1.6 |
| Max. IR Distance | N/A |
| LumiTracking | No |
| LumiSearch / LumiSearch+ | No / No |
| LumiAnalytics | Yes |
| iMD | Yes |
| VCA / VCA+ | VCA+ |
| Audio In/Out | N/A / N/A Built-in Microphone Built-in Speaker |
| Alarm In/Out | N/A |
| Memory Slot | Max 512 GB |
| Protection Rating | IP66, IK10 |
| Operating Temperature | –22 °F to +140 °F (–30 °C to +60 °C) |
| Power | PoE, 12 VDC |
The Luminys P22-4TA4 is a 4MP PTZ camera featuring a 1/2.8-inch CMOS sensor delivering 2560 x 1440 resolution with a 4x optical zoom lens, 2.8mm to 12mm. The camera includes LumiAnalytics, VCA+ (Video Content Analytics Plus), and iMD (Intelligent Motion Detection) for advanced video analytics. It features a built-in microphone and speaker for two-way audio communication. The P22-4TA4 is rated IP66 for weather resistance and IK10 for vandal protection, operating from -30°C to +60°C (-22°F to +140°F). It includes a memory card slot supporting up to 512GB for edge storage and is powered by PoE or 12 VDC. Note that LumiTracking, LumiSearch/LumiSearch+, and alarm I/O are not available on this model.
