Like Being Everywhere, All the Time
The Minuteman RPM is the ideal solution for network administrators who manage one or more remote locations. Once connected to the network, you can easily control it from virtually anywhere using a standard web browser and your password.
With a simple click, power up, down, or reboot 8-16 devices connected to the RPM individually or as a group. Automatic reboots of locked devices are also possible
RPM connects to the network, and can then be monitored and managed through a web browser or SNMP Network Management System (NMS). Notifications via e-mail, SNMP trap or SMS text message broadcast
2, 8, 16 or 24-port models are available.
Control from Anywhere
Minuteman RPMs offer a secure connection which is accessible from any device with a standard internet browser, including desktop and laptop PCs, smartphones, and tablets. From these devices, users can control and configure all aspects of the device, including:
RPM Benefits
Utilizing Minuteman’s remote power manager products allows technicians and administrators to:
Model Number | RPM1581HVN | RPM20161VN | RPM2082HVI | RPM20162VI |
Load Capacity (Max) | 12Amps | 16Amps | 16Amps | 16Amps |
INPUT PARAMETERS | ||||
Number of Phases | Single (12W +G) | |||
Nominal Voltage | 100-120VAC | 200-240VAC | ||
Frequency | 50/60Hz | |||
Input Protection | Re-settable circuit breaker | |||
OUTPUT PARAMETERS | ||||
Nominal Voltage | 100-120VAC | 200-240VAC | ||
Frequency | 50/60Hz | |||
Branch Circuit Protection | UL 60950-1 | |||
Circuit Quantity | One | |||
ENVIRONMENTAL | ||||
Operating Temperature | +32 - +122F (0 - 50C) | |||
Storage Temperature | +32 - +149F (0 - 65C) | |||
Operating/Storage Humidity | 0 - 90%, non-condensing | |||
Operating Elevation | 0 to 3,000m (0 to +10,000 ft) | |||
Storage Elevation | 0 to 15,000m (0 to +50,000 ft) | |||
PHYSICAL | ||||
Input Power Cord | 10-feet | |||
Input Plug | NEMA 5-15P | NEMA 5-20P | NEMA 6-20P | NEMA 6-20P |
Quantity Output Receptacles | 8 | 16 | 8 | 16 |
Type Output Receptacles | NEMA 5-15/20R | NEMA 5-15/20R | IEC 320 C13 | IEC 320 2 – C19, 14 – C13 |
Rack Mounting Format | Horizontal (1U) Vertical (Zero U) | Vertical (Zero U) | Horizontal (1U) Vertical (Zero U) | Vertical (Zero U) |
Net Dimension L x W x H (mm) | 3.54 x 17 x 1.73" (90 x 432 x 44) | 2.2 x 49.02 x 1.73" (56 x 1245 x 44) | 3.54" x 17" x 1.73" (90 x 432 x 44) | 2.2 x 49.02 x 1.73" (56 x 1245 x 44) |
Net Weight Lbs (Kgs) | 4.85 (2.2) | 8.82 (4.0) | 4.63 (2.1) | 8.15 (3.7) |
Ship Dimensions L x W x H (mm) | 19.9 x 8.3 x 3.5" (505 x 210 x 90) | 53.5 x 8.7 x 4.3" (1360 x 220 x 110) | 19.9 x 8.3 x 3.5" (505 x 210 x 90) | 53.5 x 8.7 x 4.3" (1360 x 220 x 110) |
Ship Weight Lbs (Kgs) | 5.51 (2.5) | 11.02 (5.0) | 5.29 (2.4) | 10.36 (4.7) |
REGULATORY COMPLIANCE | ||||
Safety/Approvals | cUL, UL 60950-1, CE |
