Hanwha - SFP-GLCM202 - Multi Mode SFP Module (LC Connectors, 1310nm)
Part number:
SFP-GLCM202
Price:

The SFP-GLCM202 is an MSA Compliant Small Form-Factor Pluggable (SFP) module that allows for an electrical interface when using a managed switch, unmanaged switch or media converter. These interchangeable SFP modules are available for use with Multi Mode optical fiber. The optical fiber SFP module is available in 1000Mbps for two fibers. They are available with LC optical connectors. The SFP modules offer 1310nm wavelengths and optical power budget to allow distances up to 2 kilometers. These SFP modules are industrially rated to perform in the most difficult operating environments.



Features:

  • 1000fx, 1310nm, 2km, LC, 2 Fiber
  • Conforms to (SFP) Small Form-Factor Pluggable Multi-Source Agreement (MSA)
  • Operating temperature: -40˚C to +75˚C
  • No in-field adjustments required
Model NumberSpeed (Mbps)

Transmission

Medium1

TX λ (nm)RX λ (nm)Max. Path LengthTX Power (dBm)RX Sensitivity (dBm)

Opt. Loss

Budget (dBm)

Number

of Fibers

Connector
SFP-GLCM2021000Multimode 131013102 km-10≤-1882LC
Name
Description
Size
Downloads
File
Datasheet
0.4mb
File
Hanwha Techwin America - NDAA Compliant Product List
0.4mb
File
SFP Module Series Manual
1.3mb
