Hanwha - SLA-5M7000D - PNM-9000VD Lens module
Part number:
SLA-5M7000D
Price:
1/1.8" 5MP CMOS with a 7.0mm fixed focal lens, FoV: H: 50.7˚, V: 37.8˚ for the PNM-9000VD
Features:
- 0.16Lux@F1.6 Color, B/W (5MP lenses)
- Selectable lens options: 3.7 / 4.6 / 7.0mm fixed lens (5MP)
| VIDEO | |
| Imaging Device | 1/1.8" 5MP CMOS |
| Effective Pixels | 2616(H)x1976(V) |
| Min. Illumination | Color : 0.16Lux(F1.6, 1/30sec, 30IRE) B/W : 0.16Lux(F1.6, 1/30sec, 30IRE) |
| LENS | |
| Focal Length (Zoom Ratio) | 7mm fixed focal |
| Max. Aperture Ratio | F1.6 |
| Angular Field of View | H: 50.7°, V: 37.8°, D: 63.8° |
| Focus Control | Fixed |
| PAN / TILT / ROTATE | |
| Pan / Tilt / Rotate Range | 90°~+90° / +36~+73° / -180°~+180° |
| MECHANICAL | |
| Color / Material | Black / Plastic |
| Dimension (W x H x D) | Ø 35.5 x 35.9 mm (Ø 1.39" x 1.41") |
