Hanwha - SBD-140PMB - Pole Mount Base (white)
Part number:
SBD-140PMB
Price:
Pole mount base made of Aluminium, black color matched to camera body. Pole Mount compatible with QNV-C8011R/C8012/C9011R, QNV-C8083R/C9083R, QND-6011/6021, QND-8011/8021, QNF-8010/9010, QND-6012R(1)/6022R(1)/6072R(1)/6082R(1), QND-7012R/7022R/7082R, QNE-8011R/8021R, LND-6012R/6022R/6072R, ANE-L6012R/L7012R
| Mechanical | |
| Color | White |
| Material | Core : Aluminum / Cap : Plastic |
| RAL code | RAL9003 |
| Product dimensions / weight | ø147.1x50.5mm(ø5.79x1.99"), 340g(0.75lb) |
| Mount Screw size | TR20 (for Camera), TR30 (Steel Strap) |
| Conduit hole | 19.1mm(3/4") (M25) |
| Supported products | QNV-C8083R/C9083R, QNV-C8011R/C8012/C9011R, QND-6012R(1)/22R(1)/72R(1)/82R(1), QND-7012R/22R/82R, QNE-8011R/21R, LND-6012R/22R/72R, ANE-L6012R/L7012R |
Name
Description
Size
Downloads
File
SBD-140PMW Specifications
0.2mb
File
Hanwha Vision America NDAA Compliant Product List
0.8mb
