Hybrid 940nm Infra-red Illuminator and White Light, High Power Dual Core LEDs, with 374' coverage distance. Interchangeable lens packs to deliver a variety of angles out of the box. Built in web browser interface for easy setup and direct Integration with DW Spectrum IPVMS, IP66, IK09, 2 Year Warranty.
SiteWatch perimeter protection
Combine the motion detectors, illuminators and horn speaker to react to events in real-time and enhance the camera’s recordings, all controlled via DW Spectrum IPVMS.
Amplify panoramic surveillance
Combine detectors and illuminators with MEGApix Pano multi-sensor and hemispheric fisheye cameras to create a formidable panoramic solution.
Interchangeable lens diffuser kit
Each SiteWatch illuminator is supplied with an interchangeable lens diffuser kit, allowing installers to easily change the angle of illumination and align perfectly with the camera’s field of view.
Features:
- Hybrid Infrared and white light LED illuminator
- Interchangeable lens pack for a variety of angles out of the box
- Direct integration with DW Spectrum IPVMS
- Create different elliptical beam profiles
- Motion-activated
- CleanView hydrophobic coating repels water, dust and grease
- Activate white light to deter intruders
- Remotely adjustable photocell and illumination levels
- 850nm IR wavelength (DW-ILHYBIP850)
- 940nm IR wavelength (DW-ILHYBIP940)
- Ultra-white ≈ 6000K white light
- 66-614ft IR coverage
- 94-374ft white light coverage
- Vibration/knock sensor
- Web interface built-in
- High-power Dual-Core LED’s with advanced, current limited and integral control circuitry
- NDAA/TAA compliant
- IP66 environmental-rated dust-tight and water-resistant
- IK 09-rated impact-resistant
| Specification | |
|---|---|
| VMS features | |
| Color rendering index (CRI) | >70 |
| Color temperature | Ultra white ≈ 6000K |
| Detection range | Up to 98.5ft (30m) programmable |
| Electronics | High efficiency surface mount high power Dual-Core™ LEDs with advanced, current limited, integral control circuity. |
| Illumination | Adjustable 10% - 100% Software adjustable |
| Lumen output | 1800 lm+ |
| Performance Remote software | DW Spectrum® |
| Performance Web viewer | Internet Explorer® browser No software or installation needed Web browser user interface Windows OS |
| Photocell | Adjustable 20 - 70 lux Software adjustable |
| Wavelength | 850nm (semi-covert). Faint red glow (DW-ILHYBIP850) 940nm (covert). Minimal visible glow (DW-ILHYBIP940) |
| Electrical | |
| Power Consumption | 26W |
| Power Requirements | PoE |
| General | |
| Housing | Robust high-quality aluminum extrusion |
| IK rating | IK09 impact-resistant in accordance with IEC/EN 62262 |
| IP rating | IP66-rated in accordance with IEC/EN 60529 |
| Mount | Powder coated stainless steel wall mount |
| Operating temperature | -58°F to 122°F (-50°C to 50°C) |
| Power cable | 1m with IP68 connector (not included) |
| Recommended PSU | Any IEEE 802.3at injector (not included) |
| Recorder Dimensions (H X W X D) | 4.33" x 6.34" x 3.07" (110 x 161 x 78mm) |
| Weight | 3 lbs (1.35 kg) |
| Certification |  |
