Speco - H16HRLN10TB - 16 Channel Hybrid Recorder 8 Hybrid (TVI or IP) + 8 IP, NDAA, 10TB
Part number:
Price:
Product Overview
Record from and manage up to sixteen cameras with H16HRL from Speco Technologies at resolutions up to 3840 x 2160. Equipped with two SATA ports, An eSATA port is available for additional storage. The recorder supports HD-TVI and IP cameras, and uses H.265 video compression to keep file sizes manageable while maintaining the best quality possible. An HDMI connection provides up to 4K UHD resolution video output.
Key Configuration
Model: H16HRLN10TB | Supports up to 5MP (HD-TVI + IP) on all channels and 4K (IP) on 8 channels | H.265 compression - Store up to 2x more than H.264 | 2 SATA ports for 10TB of storage | 1 eSATA port for an additional 8TB of storage | 4K HDMI out and VGA monitor output
Key Features
- • Object and line-crossing detection and alerts.
- • Smart Search.
- • 2-way audio communication.
- • Alarm inputs and outputs.
- • Free US-based DDNS and P2P services.
Installation Notes
15" x 10.6" x 1.8" (380mm x 268mm x 45mm)
| Specifications | |
| NDAA | Compliant |
| Number Of Channels | 16 Channel |
| Video Output Connection | HDMI, VGA |
| Recording FPS (Per Channel) | 7 FPS @ 3840 × 2160 |
| Compression Method | H.265, H.264 |
| Computer Connectivity | Windows PC |
| Mobile Platform | Android, Iphone; Speco Blue iOS®, Android™, SecureGuard® Client (Specification Sheet (H16HRLN column)) |
| Mobile connectivity | Mobile Apps, Web Browser |
| External Backup | Network, USB |
| Harddrive Size | 10TB |
| Alarm In/Out | 8/2 |
| Features | Audio, Audio Recording Capability, Bi-Directional Audio Communication, Dual Streaming, Email Notifications, Free DDNS, Multi-Zone Video Motion Detection, Multiple User Authorization, Network Time Protocol, PTZ Support, Smart Search, 4K Resolution |
| Audio Input (RCA) | RCAx8 |
| Monitor Output | 4K HDMI out and VGA |
| Video Input / Loop Output | BNC x8 |
| Video Inputs | BNC x8 |
| Audio | Yes |
| PTZ Support | Yes |
| Bi-Directional Audio Communication | Yes |
| Audio Recording Capability | Yes |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Dual Streaming | Yes |
| Free DDNS | Yes |
| Multi-Zone Video Motion Detection | Yes |
| Network Time Protocol | Yes |
| Details | |
| H.265 compression | Store up to 2x more footage than H.264 without sacrificing quality. |
| System | |
| OS | Embeded Linux |
| Video | |
| Analog Input signal | HD-TVI, AHD, CVI, CVBS |
| Analog Only Input | BNC x8 |
| Configurable Analog Inputs | 8 |
| IPC Only Input | 8CH (up to 16-CH)* |
| Network Access & Transfer Bandwidth | 32/96Mbps |
| Network Access Format | 8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps |
| Output | |
| Output | HDMIx1: 4Kx2K/1920x1080/1280x1024 |
| Output | VGAx1: 1920x1080/1280/x1024/1024x768 |
| Output | BNCx1: CVBS (used as the main or spot output) |
| Audio | |
| Input | RCAx8 |
| 2-way Audio | Take up channel one audio input |
| Local Output | RCAx1 |
| Record | |
| Record Stream | Dual stream recording |
| Resolution | 4K/5MP/4MP/1080P/720P/WD1 |
| Frame Rate | Analog: 5MP@ 12fps (PAL/NTSC), 4MP/3MP@12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) IP: 8MP and under@ 25/30fps (PAL/NTSC) |
| Bit Rate | 32~78Mbps |
| Mode | Manual, schedule, motion, sensor, intelligence |
| IP Input Resolution | 8MP/5MP/4MP/3MP/1080P/960P/720P@25fps/30fps |
| Playback | |
| Simultaneous Playback | Max 8-CH |
| Search Mode | EZ Search, museum search, time search, event search, bookmark search, snapshot search |
| Function | Play, pause, FF, FB, etc. |
| Alarm | |
| Mode | Manual, sensor, motion, exception, intelligence |
| Input | 8-CH local alarm input; Support IPC alarm input |
| Output | 2-CH local alarm input; Support IPC alarm input |
| Linkage | Record, snapshot, preset, e-mail, pop-up window, etc. |
| Network | |
| Interface | RJ45 10M/100M/100Mbps x 1 |
| Protocol | TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP |
| Web Client | Multiple online users monitoring |
| Other Viewing Platforms | Apple TV® and Amazon Fire TV® |
| Storage | |
| HDD | SATAx2, max 40TB per HDD |
| eSATA | eSATAx1 max 8TB |
| Export | |
| Local | USB, USB mobile HDD |
| Network | Yes |
| Interface | |
| USB | USB2.0x2 |
| Remote Control | Yes |
| Dimensions | |
| Power Supply | DC12V/4A |
| Power Consumption | ≤15W(without HDD) |
| Dimensions(WxDxH) | 15" x 10.6" x 1.8" (380mm x 268mm x 45mm) |
