Speco - H16HRLN4TB - 16 Channel Hybrid Recorder 8 Hybrid (TVI or IP) + 8 IP, NDAA, 4TB

Name: Speco - H16HRLN4TB - 16 Channel Hybrid Recorder 8 Hybrid (TVI or IP) + 8 IP, NDAA, 4TB
Brand: SPECO Technologies
SKU: H16HRLN4TB

Part number:

Price:

Dealers only

Add to Quote/Project Registration

Description Specifications Downloads

Product Overview

Record from and manage up to sixteen cameras with H16HRL from Speco Technologies at resolutions up to 3840 x 2160. Equipped with two SATA ports, An eSATA port is available for additional storage. The recorder supports HD-TVI and IP cameras, and uses H.265 video compression to keep file sizes manageable while maintaining the best quality possible. An HDMI connection provides up to 4K UHD resolution video output.

Key Configuration

Model: H16HRLN4TB | Supports up to 5MP (HD-TVI + IP) on all channels and 4K (IP) on 8 channels. | H.265 compression - Store up to 2x more than H.264. | 2 SATA ports for 4TB of storage. | 1 eSATA port for an additional 8TB of storage. | 4K HDMI out and VGA monitor output.

Key Features

• Object and line-crossing detection.
• Smart Search to specify a region for changes.
• 2-way audio communication.
• Free DDNS and P2P services.
• Remote viewing via web, Apple TV, Amazon Fire TV, or mobile device.

Installation Notes

15" x 10.6" x 1.8" (380mm x 268mm x 45mm)

Specifications
NDAA	Compliant
Number Of Channels	16 Channel
Recording FPS (Per Channel)	7 FPS @ 3840 × 2160
Compression Method	H.265, H.264
Computer Connectivity	Windows PC
Mobile Platform	Android, Iphone; Speco Blue iOS®, Android™, SecureGuard® Client (Specification Sheet (H16HRLN column))
Mobile connectivity	Mobile Apps, Web Browser
Harddrive Size	4TB
Features	Audio Recording Capability, Free DDNS, Multi-Zone Video Motion Detection, Multiple User Authorization, PTZ Support, 4K Resolution
Smart Search	Highlighted color to display camera records in a certain period of time, different colors refer to different record events
Details
Supports up to 5MP	HD-TVI + IP on all channels and 4K (IP) on 8 channels for high-resolution video quality.
2 SATA ports	For a total of 4TB of storage, ensuring plenty of space for recordings.
Alarm connections	4/8/16 inputs and 1/2/4 outputs for comprehensive alarm integration.
System
OS	Embeded Linux
Video
Analog Input signal	HD-TVI, AHD, CVI, CVBS
Analog Inputs	BNC x8, configurable
IPC Only Input	8CH (up to 16-CH)*
Network Access & Transfer Bandwidth	32/96Mbps
Network Access Format	8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps
Output
Output	HDMIx1: 4Kx2K/1920x1080/1280x1024
Output	VGAx1: 1920x1080/1280/x1024/1024x768
Output	BNCx1: CVBS (used as the main or spot output)
Audio
Input	RCAx8
2-way Audio	Take up channel one audio input
Local Output	RCAx1
Record
Record Stream	Dual stream recording
Resolution	4K/5MP/4MP/1080P/720P/WD1
Frame Rate	Analog: 5MP@ 12fps (PAL/NTSC), 4MP/3MP@12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) IP: 8MP and under@ 25/30fps (PAL/NTSC)
Bit Rate	32~78Mbps
Mode	Manual, schedule, motion, sensor, intelligence
Playback
Simultaneous Playback	Max 8-CH
Search Mode	EZ Search, museum search, time search, event search, bookmark search, snapshot search
Function	Play, pause, FF, FB, etc.
Alarm
Mode	Manual, sensor, motion, exception, intelligence
Input	8-CH local alarm input; Support IPC alarm input
Output	2-CH local alarm input; Support IPC alarm input
Linkage	Record, snapshot, preset, e-mail, pop-up window, etc.
Network
Interface	RJ45 10M/100M/100Mbps x 1
Protocol	TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP
Web Client	Multiple online users monitoring
Other Viewing Platforms	Apple TV® and Amazon Fire TV®
Storage
HDD	SATAx2, max 40TB per HDD
eSATA	eSATAx1 max 8TB
Export
Local	USB, USB mobile HDD
Network	Yes
Interface
USB	USB2.0x2
Remote Control	Yes
Dimensions
Power Supply	DC12V/4A
Power Consumption	≤15W(without HDD)
Dimensions(WxDxH)	15" x 10.6" x 1.8" (380mm x 268mm x 45mm)
