Speco - H24HRLN6TB - 24 Channel Hybrid Recorder - 8 TVI + 8 Hybrid (TVI or IP) + 8 IP, NDAA, 6TB
Part number:
Price:
Product Overview
The H24HRLN6TB from Speco is a 24 channel hybrid recorder - 8 TVI + 8 hybrid (TVI or IP) + 8 IP, NDAA, 6TB. This versatile device ensures exceptional performance and storage capabilities, making it an ideal solution for security monitoring needs. Speco's NDAA compliant HRLN recorders, will take your footage quality to the next level supporting up to 8MP cameras @ 30 fps
Key Configuration
Model: H24HRLN6TB
Key Features
- • Supports up to 5MP: Ensures crystal clear imaging for HD-TVI + IP cameras on all channels and 4K resolution on 8 channels for superior detail.
- • H.265 Compression: Enables you to store up to 2x more footage than the previous H.264 technology, optimizing storage space.
- • 2 SATA Ports: Allows for a total storage capacity of 6TB, accommodating extensive video footage without hassle.
- • 1 eSATA Port: Offers the option to expand storage further by adding an additional 8TB for maximum flexibility.
- • 4K HDMI Out: Delivers high-quality video output alongside a VGA monitor output for dual display convenience.
Installation Notes
15" x 10.6" x 1.8" (380mm x 268mm x 45mm)
| Specifications | |
| NDAA | Compliant |
| Number Of Channels | 24 Channel |
| Recording FPS (Per Channel) | 7 FPS @ 3840 × 2160 |
| Compression Method | H.265, H.264 |
| Computer Connectivity | Windows PC |
| Mobile Platform | Android, Iphone; Speco Blue iOS®, Android™, SecureGuard® Client (Specification Sheet (H24HRLN column)) |
| Mobile connectivity | Mobile Apps, Web Browser |
| Harddrive Size | 6TB |
| Features | Audio Recording Capability, Free DDNS, Multi-Zone Video Motion Detection, Multiple User Authorization, PTZ Support, 4K Resolution |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Details | |
| Supports up to 5MP | Ensures crystal clear imaging for HD-TVI + IP cameras on all channels and 4K resolution on 8 channels for superior detail. |
| 2 SATA Ports | Allows for a total storage capacity of 6TB, accommodating extensive video footage without hassle. |
| Comprehensive Alarm Inputs/Outputs | Includes 4/8/16 inputs and 1/2/4 outputs for versatile alarm integration. |
| System | |
| OS | Embeded Linux |
| Video | |
| Analog Input signal | HD-TVI, AHD, CVI, CVBS |
| Analog Only Input | BNC x16 |
| Configurable Analog Inputs | 8 |
| IPC Only Input | 8-CH* |
| Network Access & Transfer Bandwidth | 64/192Mbps |
| Network Access Format | 8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps |
| Output | |
| Output | HDMIx1: 4Kx2K/1920x1080/1280x1024 |
| Output | VGAx1: 1920x1080/1280/x1024/1024x768 |
| Output | BNCx1: CVBS (used as the main or spot output) |
| Audio | |
| Input | RCAx8 |
| 2-way Audio | Take up channel one audio input |
| Local Output | RCAx1 |
| Record | |
| Record Stream | Dual stream recording |
| Resolution | 4K/5MP/4MP/1080P/720P/WD1 |
| Frame Rate | Analog: 5MP@ 12fps (PAL/NTSC), 4MP/3MP@12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) IP: 8MP and under@ 25/30fps (PAL/NTSC) |
| Bit Rate | 32~78Mbps |
| Mode | Manual, schedule, motion, sensor, intelligence |
| Playback | |
| Simultaneous Playback | Max 16-CH |
| Search Mode | EZ Search, museum search, time search, event search, bookmark search, snapshot search |
| Function | Play, pause, FF, FB, etc. |
| Alarm | |
| Mode | Manual, sensor, motion, exception, intelligence |
| Input | 16-CH local alarm input; Support IPC alarm input |
| Output | 4-CH local alarm input; Support IPC alarm input |
| Linkage | Record, snapshot, preset, e-mail, pop-up window, etc. |
| Network | |
| Interface | RJ45 10M/100M/100Mbps x 1 |
| Protocol | TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP |
| Web Client | Multiple online users monitoring |
| Other Viewing Platforms | Apple TV® and Amazon Fire TV® |
| Storage | |
| HDD | SATAx2, max 40TB per HDD |
| eSATA | eSATAx1 max 8TB |
| Export | |
| Local | USB, USB mobile HDD |
| Network | Yes |
| Interface | |
| USB | USB2.0x2 |
| Remote Control | Yes |
| Dimensions | |
| Power Supply | DC12V/4A |
| Power Consumption | ≤30W(without HDD) |
| Dimensions(WxDxH) | 15" x 10.6" x 1.8" (380mm x 268mm x 45mm) |
