Speco - H6HRLN4TB - 6 Channel Hybrid Recorder 4 Hybrid (TVI or IP) + 2 IP, NDAA, 4TB
Part number:
Price:
Product Overview
The H6HRLN4TB from Speco is a 6 channel hybrid recorder that supports 4 hybrid (TVI or IP) and 2 IP channels, equipped with 4TB of storage. This device offers advanced features such as enhanced video compression, remote viewing capabilities, and intelligent alerts that provide superior surveillance solutions for both residential and commercial settings.
Key Configuration
Model: H6HRLN4TB
Key Features
- • H.265 compression: Store up to 2x more video footage compared to H.264, maximizing your storage efficiency.
- • 1 eSATA port: Connect an additional 8TB of external storage for extended recording time.
- • 4K HDMI out: Enjoy high-definition video output for superior clarity on compatible monitors.
- • Object and line crossing detection: Automated alerts for improved security and situational awareness.
- • Smart Search: Quickly locate significant events by specifying a region to review changes.
Installation Notes
11.8" x 9.8" x 1.8" (300mm x 248mm x 45mm)
| Full Specifications | |
| Channel Configuration | 6 Channels (4 Hybrid, 2 IP) |
| Storage Capacity | 4TB Internal Drive |
| Compression Format | H.265 |
| External Storage | 1 eSATA Port (up to 8TB) |
| Video Output | 4K HDMI, VGA |
| Audio Communication | 2-Way Audio Support |
| Alarm Inputs/Outputs | 4/8/16 Inputs, 1/2/4 Outputs |
| Remote Access | Web, Apple TV, Amazon Fire TV, Mobile Devices |
| Recording Types | Continuous, Motion, Analytics, Sensor |
| System | |
| Channels | 6 |
| Compression Standard | H.265 |
| OS | Embeded Linux |
| Video | |
| Analog Input signal | HD-TVI, AHD, CVI, CVBS |
| Analog Only Input | BNC x4 |
| Configurable Analog Inputs | 4 |
| IPC Only Input | 2CH (up to 6-CH)* |
| Network Access & Transfer Bandwidth | 16/40Mbps |
| Network Access Format | 8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps |
| Output | |
| HDMIx1 | 4Kx2K/1920x1080/1280x1024 |
| VGAx1 | 1920x1080/1280/x1024/1024x768 |
| BNCx1 | CVBS (used as the main or spot output) |
| Audio | |
| Input | RCAx4 |
| 2-way Audio | Take up channel one audio input |
| Local Output | RCAx1 |
| Record | |
| Record Stream | Dual stream recording |
| Resolution | 4K/5MP/4MP/1080P/720P/WD1 |
| Frame Rate - Analog | 5MP@ 12fps (PAL/NTSC), 4MP/3MP@ 12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) |
| Frame Rate - IP | 8MP@ 20fps (PAL/NTSC), Under 8MP@ 25fps/30fps (PAL/NTSC) |
| Bit Rate | 32~78Mbps |
| Mode | Manual, schedule, motion, sensor, intelligence |
| IP Input Resolution | 8MP/5MP/4MP/3MP/1080P/960P/720P@25fps/30fps |
| Playback | |
| Simultaneous Playback | Max 4-CH |
| Search Mode | EZ Search, museum search, time search, event search, bookmark search, snapshot search |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Function | Play, pause, FF, FB, etc. |
| Alarm | |
| Output | 1-CH local alarm input; Support IPC alarm input |
| Linkage | Record, snapshot, preset, e-mail, pop-up window, etc. |
| Network | |
| Interface | RJ45 10M/100Mbps x 1 |
| Protocol | TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP |
| Web Client | Multiple online users monitoring |
| Mobile Device OS | Speco Blue iOS®, Android™, SecureGuard® Client |
| Storage | |
| HDD | SATAx1, max 20TB per HDD |
| eSATA | eSATAx1 max 8TB |
| Export | |
| Local | USB, USB mobile HDD |
| Network | Yes |
| Interface | |
| USB | USB2.0x2 |
| Remote Control | Yes |
| Power | |
| Power Supply | DC12V/2A |
| Power Consumption | ≤10W(without HDD) |
| Physical & Environment | |
| Dimensions (WxDxH) | 11.8" x 9.8" x 1.8" (300mm x 248mm x 45mm) |
| Working Environment | 14°F to 122°F (-10°C" to 50°C") |
