Speco - N128NR - 128 Channel 8K H.265 NVR with Smart Analytics
Part number:
Price:
Product Overview
Speco’s N128NR is built to tackle applications with a high bandwidth in camera quantity and quality, supporting up to 16MP @ 30fps, along with a high storage capacity going up to 256TB.
Key Configuration
Model: N128NR
Key Features
- • Real time recording up to 16MP resolution (8K) @ 30fps.
- • H.265 compression – Store up to 2x more than H.264!.
- • 8K HDMI out and one VGA monitor output, additional storage via 2 eSATA ports.
- • 16 SATA ports for up to 320TB of storage max.
- • Support RAID 0, 1, 5, 6, 10.
Installation Notes
437mm x 483mm x 143mm
| Full Specifications | |
| Terabyte Size | 112TB, 128TB, 12TB, 16TB, 192TB, 20TB, 224TB, 24TB, 256TB, 30TB, 32TB, 40TB, 64TB, 6TB, 72TB, 80TB, 8TB, 96TB |
| Video | |
| Max. IP Channels | 128 |
| IP Camera | H.264/H.265 Auto Detection (Max 8MP) |
| Output | |
| Main Monitor | HDMI (Max. 8K) and VGA (Max. Full HD) |
| Sub Monitor | 3 HDMI |
| Audio | |
| Network Input | 128-CH IPC audio input |
| 2-way Audio | RCAx1 |
| Local Output | RCAx1 |
| Recording | |
| Encoding Resolutions | 16MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Codec | H.264/H.265 (Auto Detection) |
| Max Frame Rate per Channel | Any Resolution @ 30fps |
| Recording Mode | AI/Continuous/Motion/Sensor/Schedule/Manual |
| Pre-Recording | Max. 5 seconds |
| Post Recording | Max. 10 minutes |
| Search & Playback | |
| Search | EZ Search, Motion, Specific Date/Time, Event, Museum, Bookmarks, Snapshots, Log |
| Simultaneous Playback | Max 16-CH |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Playback Resolutions | 16MP/8MP/5MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Playback Functions | Play, Pause, FF, REW, Digital zoom, etc. |
| Backup | |
| Media | USB drive, USB Portable HDD, Network |
| Format | JPG, AVI, ZIP (Player+Proprietary Data) |
| Storage | |
| HDD Max Capacity of each HDD | 20TB |
| HDD Internal SATA ports | 16 |
| USB Front | 2 (USB 2.0) |
| USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Alarm | |
| Mode | Manual, Sensor, Motion, Exception, AI |
| Input | 24-CH local |
| Output | 8-CH local |
| Linkage | Record/Snapshot/Preset/Email/Pop-up Window |
| User I/F | |
| Input Method | IR Remote, Mouse |
| Network | |
| Network Bandwidth | 768Mbps |
| P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS Service |
| Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Dual Network Card | Yes |
| LAN 1 | Recorder |
| LAN 2 | Cameras |
| Network Access | |
| Mobile | iOS/Android via Speco Blue App, SecureGuard® Client |
| Web Viewer | Google Chrome®, Microsoft Edge®, Safari®, FireFox®, Windows® IE |
| VMS | SecureGuard®, Speco Blue VMS |
| Max. User Access | Max 128 users online (web client) |
| Smart Analytics | |
| People/Vehicle Detection | Line Crossing and Intrusion |
| Facial Recognition | Face Search up to 128-CH / Face Recognition Trigger Event up to 16-CH |
| LPR | Yes |
| Features | |
| Digital Zoom | Live and Playback, Free Size |
| Fisheye Dewarping | Yes |
| S.M.A.R.T | Temperature, Power On Time, Bad Sectors and Health |
| Power | |
| Power Consumption | ≤ 15W (without HDD) |
| Environment | |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Dimensions | |
| Unit | 437mm x 483mm x 143mm (17.2" x 19" x 5.6") |
Name
Description
Size
Downloads
File
Quick Installation Guide
1.3mb
File
Specification Sheet
1.4mb
File
User Manual
4.7mb
