Speco - N128NR320TB - 128 Channel 4K H.265 NVR with Analytics, 320TB
Part number:
Price:
Product Overview
Speco’s N128NR320TB is an advanced 128 Channel 4K H.265 NVR designed to handle extensive surveillance needs, supporting high-resolution video recording and superior storage capabilities. This system allows for real-time monitoring with intelligent analytics features, ensuring reliable performance in demanding security environments.
Key Configuration
Model: N128NR320TB
Key Features
- • Real time recording up to 16MP resolution (8K) @ 30fps.
- • H.265 compression stores up to 2x more than H.264.
- • 8K HDMI out and one VGA monitor output.
- • 16 SATA ports for up to 320TB of storage max.
- • Support RAID 0, 1, 5, 6, 10.
Installation Notes
437mm x 483mm x 143mm (17.2” x 19” x 5.6”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 128 Channels |
| Harddrive Size | 320TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI) |
| Resolution | 16MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Compression | H.264/H.265 |
| Bandwidth | 768Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 437mm x 483mm x 143mm (17.2” x 19” x 5.6”) |
| USB | Front 1 (USB 2.0), Rear 1 (USB 2.0) |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Resolution Supported | Up to 16MP (8K) at 30fps |
| HDMI Output | 8K HDMI and VGA |
| Storage Capacity | Up to 320TB through 16 SATA ports |
| RAID Options | RAID 0, 1, 5, 6, 10 |
| Remote Access | Free US-based DDNS and P2P services |
| Export Method | Via USB |
| Real time recording | Up to 16MP resolution (8K) at 30fps ensures crystal-clear video quality for enhanced detail. |
| Multiple outputs | 8K HDMI and VGA monitor outputs provide versatile display options for any setup. |
| Storage capacity | 16 SATA ports that support up to 320TB of storage maximize data retention for extensive surveillance. |
| RAID support | Offers RAID 0, 1, 5, 6, and 10 configurations for enhanced data security and reliability. |
| Easy video exporting | USB support allows for quick and simple video transfers and backup. |
| Specification Sheet | |
| Model | N128NR |
| Video Input Max. IP Channels | 128 |
| Video Input IP Camera | H.264/H.265 Auto Detection (Max 8MP) |
| Video Output Main Monitor | HDMI (Max. 8K) and VGA (Max. Full HD) |
| Video Output Sub Monitor | 3 HDMI |
| Audio Network Input | 128-CH IPC audio input |
| Audio 2-way Audio | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Recording Codec | H.264/H.265 (Auto Detection) |
| Recording Max Frame Rate per Channel | Any Resolution @ 30fps |
| Recording Recording Mode | AI/Continuous/Motion/Sensor/Schedule/Manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ Search, Motion, Specific Date/Time, Event, Museum, Bookmarks, Snapshots, Log |
| Search & Playback Simultaneous Playback | Max 16-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Resolutions | 16MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Search & Playback Playback Functions | Play, Pause, FF, REW, Digital zoom, etc. |
| Backup Media | USB drive, USB Portable HDD, Network |
| Backup Format | JPG, AVI, ZIP (Player+Proprietary Data) |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 16 |
| Storage USB Front | 2 (USB 2.0) |
| Storage USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | Manual, Sensor, Motion, Exception, AI |
| Alarm Input | 24-CH local |
| Alarm Output | 8-CH local |
| Alarm Linkage | Record/Snapshot/Preset/Email/Pop-up Window |
| User I/F Input Method | IR Remote, Mouse |
| Network Network Bandwidth | 768Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS Service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Dual Network Card | Yes |
| Network LAN 1 | Recorder |
| Network LAN 2 | Cameras |
| Network Access Mobile | iOS/Android via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome®, Microsoft Edge®, Safari®, FireFox®, Windows® IE |
| Network Access VMS | SecureGuard®, Speco Blue VMS |
| Network Access Max. User Access | Max 128 users online (web client) |
| Smart Analytics People/Vehicle Detection | Line Crossing and Intrusion |
| Smart Analytics Facial Recognition | Face Search up to 128-CH / Face Recognition Trigger Event up to 16-CH |
| Smart Analytics LPR | Yes |
| Features Digital Zoom | Live and Playback, Free Size |
| Features Fisheye Dewarping® S.M.A.R.T. (Self-Monitoring, Analysis, & Reporting Technology) | Temperature, Power On Time, Bad Sectors and Health |
| Power Power Consumption | ≤ 15W (without HDD) |
