Speco - N128NR40TB - 128 Channel 4K H.265 NVR with Analytics with 40TB HDD
Part number:
Price:
Product Overview
The Speco N128NR40TB 128 Channel 4K H.265 NVR with Analytics and 40TB HDD delivers advanced surveillance capabilities paired with intelligent analytics, all at no additional cost or licensing fees. This state-of-the-art NVR supports high-definition video recording, extensive storage options, and a user-friendly setup process, making it an ideal solution for comprehensive security monitoring.
Key Configuration
Model: N128NR40TB
Key Features
- • Human and Vehicle Detection: Reduces false motion alarms, ensuring accurate monitoring.
- • License Plate Detection and Recognition: Enhances security by identifying vehicles.
- • Object Detection: Alerts you to objects left behind or removed from specific areas.
- • Scene Tampering Alerts: Notifies you of any unauthorized changes to the camera's view.
- • Target Counting: Helps enforce population limits for safety management.
Installation Notes
437mm x 483mm x 143mm (17.2” x 19” x 5.6”)
| Specifications | |
| IP Channels | 128 Channels |
| Harddrive Size | 40TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, HD Resolution, Remote I/O Control, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
| Resolution | 8MP/5MP/4MP/3MP/1080P/720P |
| Compression | H.264, H.265 |
| Bandwidth | 384Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 437mm x 483mm x 143mm (17.2” x 19” x 5.6”) |
| SATA | 16 |
| USB | Front: 1 (USB 2.0), Rear: 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | RCAx1 |
| Frame Rate/Camera | 30fps |
| Compression Supported | Yes |
| HD Resolution | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| HDD Included | 40TB HDD |
| Video Resolution | Up to 8MP (4K) |
| SATA Ports | 16 SATA Ports for up to 256TB storage |
| Output Options | 4K HDMI, VGA |
| Real-time Recording | Captures video at up to 8MP resolution (4K) at 30fps for crystal-clear images. |
| Advanced H.265 Compression | Saves up to 2x more storage compared to H.264, optimizing data usage. |
| Multiple Output Options | Supports 4K HDMI and VGA monitor outputs for versatile display options. |
| Extensive Storage Capacity | Features 16 SATA ports supporting up to 256TB of storage for long-term recording. |
| EZ Copy Feature | Easily copy recordings onto a USB flash drive for convenient sharing. |
| Easy Video Exporting | Quickly transfer videos to USB devices for easy access. |
| Specification Sheet | |
| Model | NR Series |
| Video Input | Max. IP Channels |
| Video Output | Main Monitor |
| Audio Network Input | |
| Audio 2-way Audio | |
| Audio Local Output | |
| Recording Encoding Resolutions | |
| Recording Codec | |
| Recording Max Frame Rate per Channel | |
| Recording Recording Mode | |
| Recording Pre-Recording | |
| Recording Post Recording | |
| Search & Playback Search | |
| Search & Playback Simultaneous Playback | |
| Search & Playback Smart Search | |
| Search & Playback Playback Resolutions | |
| Search & Playback Playback Functions | |
| Backup Media | |
| Backup Format | |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 16 |
| Storage USB Front | 2 (USB 2.0) |
| Storage USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | |
| Alarm Input | |
| Alarm Output | |
| Alarm Linkage | |
| User I/F Input Method | |
| Network Network Bandwidth | |
| Network P2P/Dynamic DNS | |
| Network Network Protocols | |
| Network Dual Network Card | |
| Network LAN 1 | |
| Network LAN 2 | |
| Network Access Mobile | |
| Network Access Web Viewer | |
| Network Access VMS | |
| Network Access Max. User Access | |
| Smart Analytics People/Vehicle Detection | |
| Smart Analytics Facial Recognition | |
| Smart Analytics LPR | |
| Features Digital Zoom | |
| Features Fisheye Dewarping® S.M.A.R.T. (Self-Monitoring, Analysis, & Reporting Technology) | |
| Power Power Consumption | |
| Environment Operating Temperature | |
Name
Description
Size
Downloads
File
Specification Sheet
1.2mb
File
Quick Start Guide
1.3mb
File
User Manual
4.6mb
