Speco - N128NR64TB - 128 Channel 4K H.265 NVR with Analytics with 64TB HDD
Part number:
Price:
Product Overview
The Speco N128NR64TB is a state-of-the-art 128 Channel NVR designed to deliver top-notch 4K recording with intelligent analytics at no additional cost. With impressive features tailored for security and surveillance, this NVR offers extensive storage options, smart detection capabilities, and user-friendly setup, making it an ideal choice for comprehensive monitoring needs.
Key Configuration
Model: N128NR64TB
Key Features
- • Human and Vehicle Detection help to eliminate false motion alarms.
- • License plate detection and recognition.
- • Object left behind and object removed.
- • Scene tampering alerts.
- • Target counting to help enforce population limits.
Installation Notes
437mm x 483mm x 143mm (17.2” x 19” x 5.6”)
| Specifications | |
| IP Channels | 128 Channels |
| Harddrive Size | 64TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, HD Resolution, Remote I/O Control, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
| Resolution | 8MP/5MP/4MP/3MP/1080P/720P; Up to 8MP (4K) at 30fps (Details tab) |
| Compression | H.264, H.265 |
| Bandwidth | 384Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 437mm x 483mm x 143mm (17.2” x 19” x 5.6”) |
| SATA | 16 |
| USB | Front: 1 (USB 2.0), Rear: 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | RCAx1 |
| Frame Rate/Camera | 30fps |
| Compression Supported | Yes |
| HD Resolution | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Storage Capacity | 64TB built-in, up to 256TB via 16 SATA ports |
| Output Ports | 4K HDMI, VGA |
| Networking | Free DDNS, P2P |
| Audio Support | 2-way audio |
| Real-time 4K Recording | Achieve high-quality recordings at 30fps, providing detailed video evidence. |
| Multiple Output Options | 4K HDMI out and VGA monitor output for versatile display options. |
| Extensive Storage Capacity | 16 SATA ports support up to 256TB of storage for extensive video recording. |
| EZ Copy Functionality | Effortlessly transfer recordings to a USB flash drive. |
| Easy Video Exporting | Convenient export options via USB for sharing or archiving footage. |
| Specification Sheet | |
| Model | NR Series |
| Video Input | Max. IP Channels |
| Video Output | Main Monitor |
| Audio Network Input | |
| Audio 2-way Audio | |
| Audio Local Output | |
| Recording Encoding Resolutions | |
| Recording Codec | |
| Recording Max Frame Rate per Channel | |
| Recording Recording Mode | |
| Recording Pre-Recording | |
| Recording Post Recording | |
| Search & Playback Search | |
| Search & Playback Simultaneous Playback | |
| Search & Playback Smart Search | |
| Search & Playback Playback Resolutions | |
| Search & Playback Playback Functions | |
| Backup Media | |
| Backup Format | |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 16 |
| Storage USB Front | 2 (USB 2.0) |
| Storage USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | |
| Alarm Input | |
| Alarm Output | |
| Alarm Linkage | |
| User I/F Input Method | |
| Network Network Bandwidth | |
| Network P2P/Dynamic DNS | |
| Network Network Protocols | |
| Network Dual Network Card | |
| Network LAN 1 | |
| Network LAN 2 | |
| Network Access Mobile | |
| Network Access Web Viewer | |
| Network Access VMS | |
| Network Access Max. User Access | |
| Smart Analytics People/Vehicle Detection | |
| Smart Analytics Facial Recognition | |
| Smart Analytics LPR | |
| Features Digital Zoom | |
| Features Fisheye Dewarping® S.M.A.R.T. (Self-Monitoring, Analysis, & Reporting Technology) | |
| Power Power Consumption | |
| Environment Operating Temperature | |
