Speco - N128NR96TB - 128 Channel 4K H.265 NVR with Analytics with 96TB HDD
Part number:
Price:
Product Overview
The Speco N128NR96TB 128 Channel 4K H.265 NVR with Analytics and 96TB HDD is a high-performance network video recorder designed to ensure top-level security and surveillance. This innovative device offers a multitude of smart features, including advanced analytics at no extra cost, making it an ideal choice for both commercial and residential applications.
Key Configuration
Model: N128NR96TB
Key Features
- • Human and Vehicle Detection help to eliminate false motion alarms.
- • License plate detection and recognition.
- • Object left behind and object removed.
- • Scene tampering alerts.
- • Target counting to help enforce population limits.
Installation Notes
437mm x 483mm x 143mm (17.2” x 19” x 5.6”)
| Specifications | |
| IP Channels | 128 Channels |
| Harddrive Size | 96TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, HD Resolution, Remote I/O Control, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
| Resolution | 8MP/5MP/4MP/3MP/1080P/720P |
| Compression | H.264, H.265 |
| Bandwidth | 384Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 437mm x 483mm x 143mm (17.2” x 19” x 5.6” |
| SATA | 16 |
| USB | Front: 1 (USB 2.0), Rear: 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | RCAx1 |
| Frame Rate/Camera | 30fps |
| Compression Supported | Yes |
| HD Resolution | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Video Input | Up to 4K resolution (8MP) |
| Maximum Storage Capacity | 256TB (16 SATA ports) |
| Output Ports | 1x 4K HDMI, 1x VGA |
| Real-Time Recording | Capture crisp video at 4K resolution (8MP) with real-time 30fps recording capability. |
| Multiple Output Options | Enjoy flexibility with 4K HDMI and VGA output capabilities. |
| Storage Capacity | Features 16 SATA ports supporting a maximum storage of 256TB. |
| EZ Copy | Copy videos to a USB flash drive with just a few clicks. |
| Free DDNS and P2P Services | Use US-based DDNS and P2P services without additional costs. |
| USB Video Export | Export videos effortlessly with USB support. |
| Specification Sheet | |
| Model | NR Series |
| Video Output | Main Monitor |
| Audio Network Input | |
| Audio 2-way Audio | |
| Audio Local Output | |
| Recording Encoding Resolutions | |
| Recording Codec | |
| Recording Max Frame Rate per Channel | |
| Recording Recording Mode | |
| Recording Pre-Recording | |
| Recording Post Recording | |
| Search & Playback Search | |
| Search & Playback Simultaneous Playback | |
| Search & Playback Smart Search | |
| Search & Playback Playback Resolutions | |
| Search & Playback Playback Functions | |
| Backup Media | |
| Backup Format | |
| Storage HDD Max Capacity of each HDD | |
| Storage HDD Internal SATA ports | |
| Storage USB Front | |
| Storage USB Rear | |
| Alarm Mode | |
| Alarm Input | |
| Alarm Output | |
| Alarm Linkage | |
| User I/F Input Method | |
| Network Network Bandwidth | |
| Network P2P/Dynamic DNS | |
| Network Network Protocols | |
| Network Dual Network Card | |
| Network LAN 1 | |
| Network LAN 2 | |
| Network Access Mobile | |
| Network Access Web Viewer | |
| Network Access VMS | |
| Network Access Max. User Access | |
| Smart Analytics People/Vehicle Detection | |
| Smart Analytics Facial Recognition | |
| Smart Analytics LPR | |
| Features Digital Zoom | |
| Features Fisheye Dewarping® S.M.A.R.T. (Self-Monitoring, Analysis, & Reporting Technology) | |
| Power Power Consumption | |
| Environment Operating Temperature | |
