Speco - N16NRX16TB - 16 Channel Facial Recognition Recorder with Smart Analytics, 16TB
Part number:
Price:
Product Overview
Introducing the Speco N16NRX16TB 16 Channel Facial Recognition Recorder with Smart Analytics - a state-of-the-art surveillance solution designed to elevate your security operations. This recorder supports real-time recording of up to 16MP resolution at 30fps, ensuring crystal-clear video quality. With advanced features such as H.265 compression, facial recognition, and smart search capabilities, this recorder offers unparalleled performance and usability for any security environment.
Key Configuration
Model: N16NRX16TB
Key Features
- • Real-time Recording: Up to 16MP resolution (8K) at 30fps, providing ultra-high definition video clarity for critical security footage.
- • H.265 Compression: Enables storage of up to 2x more data compared to H.264, optimizing storage space without compromising video quality.
- • Multiple Output Options: 4K HDMI out and one VGA monitor output allow for flexible video display setups for various environments.
- • Facial Recognition: Advanced technology for identifying individuals, enhancing security protocols through precise monitoring.
- • Object and Line Crossing Detection: Intelligent alerts for any identified movements, ensuring timely responses to potential security breaches.
Installation Notes
380mm x 268mm x 45mm (15.0" x 10.6" x 2.0")
| Full Specifications | |
| Product Model | Speco N16NRX16TB |
| Number of Channels | 16 |
| Recording Resolution | Up to 16MP (8K) |
| Frame Rate | 30fps |
| Compression Type | H.265 |
| Outputs | 4K HDMI, VGA |
| Facial Recognition | Yes |
| Detection Features | Object and line crossing alerts |
| Smart Search Capability | Yes |
| Remote Access Services | Free US-based DDNS and P2P |
| Remote Viewing | Web browser and mobile device compatible |
| Video Export Method | USB |
| Remote Control | Included |
| Rack Mounting | Rack ears included (N16NRX only) |
| Video | |
| Max. IP Channels | 16 |
| IP Camera | H.265/H.264 auto detection (max. 16MP) |
| Main Monitor | HDMI (max. 4K) and VGA (max. full HD) |
| Audio | |
| Network Input | 16-CH IPC audio input |
| Local Input | RCAx1 |
| Local Output | RCAx1 |
| Recording | |
| Resolutions | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Codec | H.264/H.265 (auto detection) |
| Max Frame Rate per Channel | 16MP @ 30fps |
| Recording Mode | Analytics/continuous/motion/sensor/schedule/manual |
| Pre-Recording Max. | 5 seconds |
| Post Recording Max. | 10 minutes |
| Search & Playback | |
| Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Simultaneous Playback | Max. 16-CH |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup | |
| Media | USB drive, network |
| Format | MP4, JPG, AVI, proprietary format (player included) |
| Storage | |
| Max Capacity of each HDD | 40TB |
| Internal SATA ports | 2 |
| USB Front | 1 (USB 2.0) |
| USB Rear | 1 USB 2.0 1 USB 3.0 |
| Alarm | |
| Mode | Manual, sensor, motion, exception, intelligence |
| Input | 8-CH local |
| Linkage | Record/snapshot/preset/email/pop-up window |
| Network | |
| Network Bandwidth | 192Mbps |
| P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Mobile | iOS®/Android™ via Speco Blue App, SecureGuard® Client |
| Web Viewer | Google Chrome®, Microsoft Edge®, Firefox®, Safari® |
| VMS/CMS | Speco Blue VMS, SecureGuard® |
| Max. User Access | Max 10 users online (web client) |
| Features | |
| Digital Zoom | Live and playback, free size |
| Fisheye Dewraping* | Yes |
| S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) | Temperature, power on time, bad sectors, and health |
| People/Vehicle Detection | Line crossing and intrusion |
| LPR | 16-CH |
| Power | |
| Power Consumption | ≤ 15W (without HDD) |
| PoE Ports | 16 |
| Power per PoE Port Max (802.3at) | 30W |
| Total PoE Power Budget (802.3af/at) | 150W |
| Environment | |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C ) |
| Operating Humidity | 10% ~ 90% humidity |
| Dimensions Unit | 380mm x 268mm x 45mm (15.0" x 10.6" x 2.0") |
