Speco - N16NRX40TB - 8K H.265 NVR with Facial Recognition and Smart Analyticswith, 40TB
Part number:
Price:
Product Overview
The N16NRX40TB from Speco is an advanced NDAA compliant 8K H.265 NVR designed to elevate your surveillance capabilities. With support for up to 16MP camera resolutions at 30 fps, this robust recorder seamlessly integrates advanced facial recognition and smart analytics to enhance security monitoring and provide unparalleled footage quality.
Key Configuration
Model: N16NRX40TB
Key Features
- • Real-time Recording: Capture footage in stunning 16MP resolution (8K) at 30 fps for crystal-clear images.
- • H.265 Compression: Store up to twice as much data compared to H.264.
- • Multiple Output Options: Equipped with 4K HDMI output and one VGA monitor output.
- • Enhanced Storage: Features 2 SATA ports allowing for a maximum of 40TB storage.
- • Advanced Facial Recognition: Employ cutting-edge facial detection technology.
Installation Notes
380mm x 268mm x 45mm (15.0” x 10.6” x 2.0”)
| Specifications | |
| IP Channels | 16 Channels |
| Harddrive Size | 40TB |
| Protocols | speco Protocols |
| Features | Compression Supported, DDNS Functionality, H.264 Compression, Supports the Full HD Output (HDMI) |
| Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Compression | H.265 |
| Bandwidth | 192Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 380mm x 268mm x 45mm (15.0” x 10.6” x 2.0”) |
| Power Consumption | ≤ 15W (without HDD) |
| SATA | 2 |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | 16-CH IPC audio input |
| Frame Rate/Camera | 16MP @ 30fps |
| DDNS Functionality | Yes |
| HDMI Output (720p/1080p) | Yes |
| H.264 Compression | Yes |
| Details | |
| Video Resolution | Up to 16MP (8K) |
| Storage Capacity | Up to 40TB (2 SATA ports) |
| Output Ports | 1 x 4K HDMI, 1 x VGA |
| Real-time Recording | Capture footage in stunning 16MP resolution (8K) at 30 fps for crystal-clear images. |
| H.265 Compression | Store up to twice as much data compared to H.264, maximizing storage capacity while maintaining high-quality video. |
| Multiple Output Options | Equipped with 4K HDMI output and one VGA monitor output for versatile viewing setups. |
| Enhanced Storage | Features 2 SATA ports allowing for a maximum of 40TB storage, accommodating extensive video data without issues. |
| Free Services | Enjoy complimentary US-based DDNS and P2P services for simplified remote access and management. |
| Simple Video Export | Easily export video footage via USB for convenient sharing or documentation. |
| Rack Ears | The N16NRX includes rack ears for easy installation in standard racks. |
| Technical Specification | |
| Model | N16NRX |
| Video Input Max. IP Channels | 16 |
| Video Input IP Camera | H.265/H.264 auto detection (max. 16MP) |
| Video Output Main Monitor | HDMI (max. 4K) and VGA (max. full HD) |
| Audio Network Input | 16-CH IPC audio input |
| Audio Local Input | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Max Frame Rate per Channel | 16MP @ 30fps |
| Recording Recording Mode | Analytics/continuous/motion/sensor/schedule/manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max. 16-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (player included) |
| Storage HDD Max Capacity of each HDD | 40TB |
| Storage HDD Internal SATA ports | 2 |
| Storage USB Front | 1 USB 2.0 |
| Storage USB Rear | 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | Manual, sensor, motion, exception, intelligence |
| Alarm Input | 8-CH local |
| Alarm Output | 4-CH local |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 192Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome®, Microsoft Edge®, Firefox®, Safari® |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard® |
| Network Access Max. User Access | Max 10 users online (web client) |
| Features Digital Zoom | Live and playback, free size |
| Features Fisheye Dewraping | Yes |
| Features S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) | Temperature, power on time, bad sectors, and health |
| Smart Analytics People/Vehicle Detection | Line crossing and intrusion |
| Smart Analytics Facial Recognition | Face recognition trigger event up to 16-CH |
| Smart Analytics LPR | 16-CH |
| Power PoE Ports | 16 |
| Power Power per PoE Port Max (802.3at) | 30W |
| Power Total PoE Power Budget (802.3af/at) | 150W |
| Environment Operating Humidity | 10% - 90% humidity |
