Speco - N32NRN - 4K 32 Channel NDAA Compliant NVR with Smart Analytics
Part number:
Price:
Product Overview
4K 32 Channel NDAA Compliant NVR with Smart Analytics
Key Configuration
Model: N32NRN
Key Features
- • Human Detection.
- • Vehicle Detection.
- • License plate detection.
- • Recognition.
- • Object left behind detection.
Installation Notes
445mm x 436mm x 90mm (2u) (17.5" x 17.2" x 3.5")
| Full Specifications | |
| Real-time recording | up to 8MP resolution (4K) at 30fps & up to 12MP resolution at 20fps |
| Compression | H.265 |
| HDMI Output | 4K HDMI out and one VGA monitor output |
| Storage | 8 SATA ports for up to 20TB of storage per SATA |
| Technical Specification NVR Video Recorder | |
| Model | NRN |
| Video | Input | Max. IP Channels | 32 |
| Video | Input | IP Camera | H.264/H.265 Auto Detection (Max. 8MP) |
| Video | Output | Main Monitor | HDMI (Max. 4K) and VGA (Max. Full HD) |
| Video | Output | VGA | VGA |
| Audio | Network Input | 32 Ch. audio input |
| Audio | 2-way Audio | RCAx1 |
| Audio | Local Output | RCAx1 |
| Recording | Encoding Resolutions | 12MP/8MP/5MP/4MP/3MP/1080P/720P |
| Recording | Codec | H.264/H.265 (Auto Detection) |
| Recording | Max Frame Rate per Channel | 12MP 20fps/8MP or lower @30fps |
| Recording | Recording Mode | Analytics/Continuous/Motion/Sensor/Schedule/Manual |
| Recording | Pre-Recording | Max. 5 seconds |
| Recording | Post Recording | Max. 10 minutes |
| Search & Playback | Search | EZ Search, Motion, Specific Date/Time, Event, Museum, Bookmarks, Snapshots, Log |
| Search & Playback | Simultaneous Playback | Max. 16 Ch. |
| Search & Playback | Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback | Playback Functions | Play, Pause, FF, Rew, Digital Zoom, etc. |
| Backup | Media | USB drive, Network |
| Backup | Format | JPG, AVI, Proprietary Format (Includes Player) |
| Storage | HDD | Max Capacity of each HDD | 20TB |
| Storage | HDD | Internal SATA ports | 8 |
| Storage | USB | Front | 1 USB 2.0 |
| Storage | USB | Rear | 1 USB 2.0, 1 USB 3.0 |
| Alarm | Mode | Manual, Sensor, Motion, Exception, AI |
| Alarm | Input/Output | 16ch local inputs, 9ch output |
| Alarm | Linkage | Record/Snapshot/Preset/Email/Pop-up Window |
| User I/F | Input Method | IR Remote, Mouse |
| Network | Network Bandwidth | 320Mbps |
| Network | P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS Service |
| Network | Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access | Mobile | iOS/Android via Speco Blue App, SecureGuard* Client |
| Network Access | VMS/CMS | Speco Blue VMS, SecureGuard* |
| Network Access | Max. User Access | Max 10 users online (web client) |
| Features | Digital Zoom | Live and Playback, Free Size |
| Features | Fisheye Dewraping* | Yes (Web client and mobile app) |
| Features | S.M.A.R.T (Self-Monitoring, Analysis Temperature & Reporting Technology) | Temperature, Power On Time, Bad Sectors and Health |
| Smart Analytics | People / Vehicle Detection | Line Crossing, Intrusion, People Counting |
| Smart Analytics | Facial Recognition | Store up to 10,000 face images Up to 6CH for event Face Search up to 32CH |
| Smart Analytics | LPR | LPR on all 32CH, store up to 50,000 License Plate images |
| Smart Analytics | Others | Object abandoned/missing, trip wire |
| Power | Power Consumption | ≤ 30W (without HDD) |
| Environment | Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Environment | Operating Humidity | 10% - 90% humidity |
