Speco - N32NRN100TB - 32 Channel 4K Network Video Recorder with 2 Plug & Play Ports, 100TB
Part number:
Price:
Product Overview
The NRN Family by Speco Technologies delivers advanced analytical capabilities with no additional charges or licensing, enhancing security systems with features like human and vehicle detection and license plate recognition. Speco’s NDAA compliant N32NRN will allow you to separate your camera and main network traff ic ensuring eff icient bandwidth to view up to 12MP at 20FPS.
Key Configuration
Model: N32NRN100TB
Key Features
- • Two LAN Ports to help isolate camera traffic from the main network.
- • Real time recording up to 12MP resolution (4K) at 20fps and 8MP resolution at 30fps.
- • H.265 compression - Store up to 2x more than H.264!.
- • 2 HDMI out and one VGA monitor output.
- • 8 SATA ports for up to 20TB of storage per SATA for a maximum of 160TB.
Installation Notes
445mm x 436mm x 90mm (2u) (17.5” x 17.2” x 3.5”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 32 Channels |
| Harddrive Size | 100TB |
| Protocols | speco Protocols |
| Features | AI Analytics, Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Remote I/O Control, Supports the Full HD Output (HDMI), Two-way Audio, Facial Recognition |
| Resolution | 12MP/8MP/5MP/4MP/3MP/1080P/720P |
| Compression | H.264/H.265 (auto detection) |
| Bandwidth | 320Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 445mm x 436mm x 90mm (2u) (17.5” x 17.2” x 3.5”) |
| Power Consumption | ≤ 30W (without HDD) |
| SATA | 8 |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | RCAx1 |
| Frame Rate/Camera | 12MP 20fps/8MP or lower @30fps |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Storage Capacity | Up to 20TB per SATA port, 8 SATA ports |
| Video Output | 1 x 4K HDMI, 1 x VGA |
| Real Time Recording | Record in stunning 8MP resolution (4K) at 30fps or 12MP at 20fps for clear visuals. |
| 265 Compression Technology | Optimizes storage efficiency, allowing for up to 2x more video storage compared to H.264. |
| Multiple Video Outputs | Features 4K HDMI and a VGA output to connect to various display systems. |
| 8 SATA Ports | Supports up to 20TB of storage per port, providing extensive storage capabilities. |
| EZ Copy Functionality | Allows quick copying of video content to a USB drive, simplifying export processes. |
| Easy Video Export | Streamlines the process of video file exporting via USB. |
| Technical Specification | |
| Model | N32NRN |
| Video Input Max. IP Channels | 32 |
| Video Input IP Camera | H.264/H.265 Auto Detection (Max. 8MP) |
| Video Output Main Monitor | HDMI (Max. 4K) and VGA (Max. Full HD) |
| Video Output VGA | VGA |
| Audio Network Input | 32 Ch. audio input |
| Audio 2-way Audio | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Recording Mode | Analytics/Continuous/Motion/Sensor/Schedule/Manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ Search, Motion, Specific Date/Time, Event, Museum, Bookmarks, Snapshots, Log |
| Search & Playback Simultaneous Playback | Max. 16 Ch. |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Functions | Play, Pause, FF, Rew, Digital Zoom, etc. |
| Backup Media | USB drive, Network |
| Backup Format | JPG, AVI, Proprietary Format (Includes Player) |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 8 |
| Storage USB Front | 1 USB 2.0 |
| Storage USB Rear | 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | Manual, Sensor, Motion, Exception, AI |
| Alarm Input/Output | 16ch local inputs, 9ch output |
| Alarm Linkage | Record/Snapshot/Preset/Email/Pop-up Window |
| User I/F Input Method | IR Remote, Mouse |
| Network Network Bandwidth | 320Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS Service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS/Android via Speco Blue App, SecureGuard* Client |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard* |
| Network Access Max. User Access | Max 10 users online (web client) |
| Features Digital Zoom | Live and Playback, Free Size |
| Features Fisheye Dewraping* | Yes (Web client and mobile app) |
| Features S.M.A.R.T (Self-Monitoring, Analysis Temperature & Reporting Technology) | Temperature, Power On Time, Bad Sectors and Health |
| Smart Analytics People / Vehicle Detection | Line Crossing, Intrusion, People Counting |
| Smart Analytics Facial Recognition | Store up to 10,000 face images Up to 6CH for event Face Search up to 32CH |
| Smart Analytics LPR | LPR on all 32CH, store up to 50,000 License Plate images |
| Smart Analytics Others | Object abandoned/missing, trip wire |
| Environment Operating Humidity | 10% - 90% humidity |
Name
Description
Size
Downloads
File
Specification Sheet
1mb
File
Quick Start Guide
1.1mb
File
User Manual
4.7mb
