Speco - N32NRN140TB - 32 Channel 4K Network Video Recorder with 2 Plug & Play Ports, 140TB
Part number:
Price:
Product Overview
The Speco NRN Family, in conjunction with specific Speco Technologies analytic cameras, offers a wide array of intelligent analytics at no additional cost and with no licensing fees. This innovative surveillance solution combines advanced technology with user-friendly features to provide enhanced security and ease of use.
Key Configuration
Model: N32NRN140TB
Key Features
- • Real time recording up to 8MP resolution (4K) at 30fps & up to 12MP resolution at 20fps.
- • 265 compression – Store up to 2x more than H.264.
- • 4K HDMI out and one VGA monitor output.
- • 8 SATA ports for up to 20TB of storage per SATA.
- • EZ Camera: quickly discover and install all Speco IP cameras.
Installation Notes
445mm x 436mm x 90mm (2u) (17.5” x 17.2” x 3.5”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 32 Channels |
| Harddrive Size | 140TB |
| Protocols | speco Protocols |
| Features | AI Analytics, Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Remote I/O Control, Supports the Full HD Output (HDMI), Two-way Audio, Facial Recognition |
| Resolution | 12MP/8MP/5MP/4MP/3MP/1080P/720P |
| Compression | H.264/H.265 (auto detection) |
| Bandwidth | 320Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 445mm x 436mm x 90mm (2u) (17.5” x 17.2” x 3.5”) |
| Power Consumption | ≤ 30W (without HDD) |
| SATA | 8 |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | RCAx1 |
| Frame Rate/Camera | 12MP 20fps/8MP or lower @30fps |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Frame Rate | 30fps at 4K, 20fps at 12MP |
| Encoding | H.265 |
| SATA Capacity | Up to 20TB per SATA |
| Outputs | 4K HDMI and VGA |
| Video Export | EZ Copy via USB |
| Audio Support | 2-way audio |
| Real-time Recording | Captures up to 8MP resolution (4K) at 30fps and up to 12MP resolution at 20fps for crystal-clear images. |
| 265 Compression | Enables storage of up to 2x more footage than H.264, maximizing storage efficiency. |
| 8 SATA Ports | Provides up to 20TB of storage per SATA, ensuring ample space for recordings. |
| EZ Copy | Easily copy video footage to a USB flash drive for convenience. |
| Easy Video Exporting | User-friendly video export options via USB for quick transfers. |
| Technical Specification | |
| Model | N32NRN |
| Video Input | Max. IP Channels 32 |
| Video Output | Main Monitor HDMI (Max. 4K) and VGA (Max. Full HD) |
| Audio Network Input | 32 Ch. audio input |
| Audio 2-way Audio | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 12MP/8MP/5MP/4MP/3MP/1080P/720P |
| Recording Codec | H.264/H.265 (Auto Detection) |
| Recording Recording Mode | Analytics/Continuous/Motion/Sensor/Schedule/Manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ Search, Motion, Specific Date/Time, Event, Museum, Bookmarks, Snapshots, Log |
| Search & Playback Simultaneous Playback | Max. 16 Ch. |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Functions | Play, Pause, FF, Rew, Digital Zoom, etc. |
| Backup Media | USB drive, Network |
| Backup Format | JPG, AVI, Proprietary Format (Includes Player) |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 8 |
| Storage USB Front | 1 USB 2.0 |
| Storage USB Rear | 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | Manual, Sensor, Motion, Exception, AI |
| Alarm Input/Output | 16ch local inputs, 9ch output |
| Alarm Linkage | Record/Snapshot/Preset/Email/Pop-up Window |
| User I/F Input Method | IR Remote, Mouse |
| Network Network Bandwidth | 320Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS Service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS/Android via Speco Blue App, SecureGuard* Client |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard* |
| Network Access Max. User Access | Max 10 users online (web client) |
| Features Digital Zoom | Live and Playback, Free Size |
| Features Fisheye Dewraping* | Yes (Web client and mobile app) |
| Features S.M.A.R.T (Self-Monitoring, Analysis Temperature & Reporting Technology) | Temperature, Power On Time, Bad Sectors and Health |
| Smart Analytics People / Vehicle Detection | Line Crossing, Intrusion, People Counting |
| Smart Analytics Facial Recognition | Store up to 10,000 face images Up to 6CH for event Face Search up to 32CH |
| Smart Analytics LPR | LPR on all 32CH, store up to 50,000 License Plate images |
| Smart Analytics Others | Object abandoned/missing, trip wire |
| Environment Operating Humidity | 10% - 90% humidity |
