Speco - N32WNRN80TB - 32 Channel 4K Network Video Recorder with 2 Plug & Play Ports, 80TB
Part number:
Price:
Product Overview
The N32WNRN80TB from Speco is a high-performance 32 channel 4K H.265 network video recorder designed for professional surveillance. 4K 32 Channel Facial Recognition, NDAA Compliant IP 32 Channel NVR with 2 Ethernet Ports.
Key Configuration
Model: N32WNRN80TB
Key Features
- • Two LAN Ports to help isolate camera traffic from the main network.
- • Real time recording up to 12MP resolution (4K) at 20fps and 8MP resolution at 30fps.
- • H.265 compression – Store up to 2x more than H.264!.
- • 2 HDMI out and one VGA monitor output.
- • 4 SATA ports for up to 20TB of storage per SATA for a maximum of 80TB.
Installation Notes
489mm x 413mm x 89mm (19.25” x 16.25” x 3.5”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 32 Channels |
| Harddrive Size | 80TB |
| Protocols | speco Protocols |
| Features | AI Analytics, Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Remote I/O Control, Supports the Full HD Output (HDMI), Two-way Audio, Facial Recognition |
| Resolution | 12MP/8MP/5MP/4MP/3MP/1080P/720P |
| Compression | H.264/H.265 (auto detection) |
| Bandwidth | 320Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 489mm x 413mm x 89mm (19.25” x 16.25” x 3.5”) |
| Power Consumption | ≤ 30W (without HDD) |
| SATA | 4; Max Capacity of each HDD (Specification Sheet) |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | RCAx1 |
| Frame Rate/Camera | 12MP 20fps/8MP or lower @30fps |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Remote I/O Control | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Video Resolution | Up to 12MP (4K) at 20fps, 8MP at 30fps |
| Output Ports | 2 HDMI, 1 VGA |
| LAN Ports | 2 |
| RAID Support | 0, 1, 5, 6, 10 |
| Facial Recognition Support | Up to 6 Channels |
| Copy Functionality | Easily copy footage to a USB flash drive for quick sharing. |
| Real-Time Recording | Supports up to 12MP resolution (4K) at 20fps and 8MP at 30fps for high-quality footage. |
| Multiple Output Options | 2 HDMI and one VGA output for versatile display configurations. |
| Storage Capacity | 4 SATA ports supporting up to 20TB each, totaling a remarkable 80TB. |
| RAID Support | Configurable RAID options (0,1,5,6,10) for flexible storage and data protection. |
| Facial Recognition | Advanced capability supporting up to 6 channels for enhanced identification. |
| Easy Video Export | Quick video exporting via USB for convenient sharing. |
| Simultaneous Output | Supports both HDMI and VGA video output for multi-display setups. |
| Specification Sheet | |
| Model | N32WNRN |
| Video | Input |
| IP Camera | H.264/H.265 Auto Detection (Max. 8MP) |
| Main Monitor | HDMI (Max. 4K) and VGA (Max. Full HD) |
| VGA | VGA |
| Recording | Encoding Resolutions |
| Simultaneous Playback | Max. 16 Ch. |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Playback Functions | Play, Pause, FF, Rew, Digital Zoom, etc. |
| Backup | Media |
| Alarm | Mode |
| User I/F | Input Method |
| Network | Network Bandwidth |
| Network Access | Mobile |
| S.M.A.R.T | Temperature, Power On Time, Bad Sectors and Health |
| Smart Analytics | People / Vehicle Detection |
| LPR | LPR on all 32CH, store up to 50,000 License Plate images |
| Others | Object abandoned/missing, trip wire |
| Power | Power Consumption |
| Environment | Operating Temperature |
| Operating Humidity | 10% - 90% humidity |
