Speco - N4NRM20TB - 4K H.265 NVR with Smart Analytics 4 Channel with 4 Built-In PoE Ports with, 20TB
Part number:
Price:
Product Overview
The N4NRM20TB from Speco is a top-tier 4K H.265 NVR designed for optimal security and surveillance. With support for up to 8MP cameras at 30 fps, it brings unparalleled image clarity and storage efficiency—allowing you to store up to twice as much footage thanks to advanced H.265 compression. Speco’s NDAA compliant NRM recorders, will take your footage quality to the next level supporting up to 16MP cameras @ 30 fps.
Key Configuration
Model: N4NRM20TB
Key Features
- • Real-time Recording: Capture high-definition footage in real-time at 4K resolution (8MP) and 30fps for stunning clarity.
- • Efficient Compression: H.265 technology enables you to store up to 2x more video compared to the older H.264 format.
- • Multiple Output Options: Comes with 4K HDMI and VGA outputs.
- • Expand Your Storage: Includes 1 SATA port capable of supporting up to 20TB of storage.
- • Smart Analytics: Features facial detection and object/line crossing alerts.
Installation Notes
380mm x 268mm x 45mm (15.0” x 10.6” x 1.8”)
| Specifications | |
| IP Channels | 4 Channels |
| Harddrive Size | 20TB |
| Protocols | speco Protocols |
| Features | Compression Supported, DDNS Functionality, H.264 Compression, Supports the Full HD Output (HDMI) |
| Resolution | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Compression | H.265 |
| Bandwidth | 160Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 380mm x 268mm x 45mm (15.0” x 10.6” x 1.8”) |
| Power Consumption | ≤ 10W (without HDD) |
| SATA | 1 |
| USB | 1 (USB 2.0) |
| Audio | 16-CH IPC audio input |
| Frame Rate/Camera | Any resolution @ 30fps |
| DDNS Functionality | Yes |
| HDMI Output (720p/1080p) | Yes |
| H.264 Compression | Yes |
| Details | |
| Video Resolution | Up to 8MP (4K) |
| Frames Per Second | 30 fps |
| SATA Ports | 1 (supports up to 20TB) |
| Outputs | 4K HDMI, VGA |
| Export Method | USB |
| Real-time Recording | Capture high-definition footage in real-time at 4K resolution (8MP) and 30fps for stunning clarity. |
| Efficient Compression | H.265 technology enables you to store up to 2x more video compared to the older H.264 format, maximizing your storage potential. |
| Multiple Output Options | Comes with 4K HDMI and VGA outputs, ensuring compatibility with a wide range of monitors and setups. |
| Expand Your Storage | Includes 1 SATA port capable of supporting up to 20TB of storage, perfect for extensive video retention. |
| Remote Accessibility | With free US-based DDNS and P2P services, remote viewing is easy through web browsers or mobile devices. |
| Easy Video Export | Quickly export video footage via USB for sharing or archival purposes. |
| Specification Sheet | |
| Model | NRM Series |
| Video Input Max. IP Channels | 4 |
| Video Input IP Camera | H.264/H.265 auto detection (max. 8MP) |
| Video Output Main Monitor | HDMI (max. 4K) and VGA (max. Full HD) |
| Audio Network Input | 4-CH IPC audio input |
| Audio Local Input | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Recording Mode | Analytics/continuous/motion/sensor/schedule/manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max 4-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Resolutions | 1 x 8MP @ 30 FPS, 6 x 1080P @ 30 FPS |
| Search & Playback Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage HDD Max Capacity of each HDD | 40TB |
| Storage HDD Internal SATA ports | 1 |
| Storage USB Front | 1 (USB 2.0) |
| Storage USB Rear | 1 (USB 2.0) |
| Alarm Mode | Manual, sensor, motion, exception, intelligence |
| Alarm Input/ Output | IPC alarm in / IPC alarm out |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 80Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard* Client |
| Network Access Web Viewer | Google Chrome*, Microsoft Edge*, Firefox* |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard* |
| Network Access Max. User Access | Max 64 users access |
| Features Digital Zoom | Live and playback, free size |
| Features S.M.A.R.T. | Temperature, power on time, bad sectors, and health |
| Smart Analytics People/Vehicle Detection | 4 |
| Smart Analytics Facial Detection | 4 |
| Smart Analytics License Plate Recognition | 4 |
| Power PoE Ports | 4 |
| Power Power per PoE Port Max (802.3at) | 30W |
| Power Total PoE Power Budget (802.3af/at) | 48W |
| Environment Operating Humidity | 10% - 90% humidity |
