Speco - N4NRV10TB - 4 Channel Network Video Recorder with 4 Built-In PoE Ports, 10TB
Part number:
Price:
Product Overview
Introducing the Speco N4NRV10TB, a powerful 4 Channel Network Video Recorder designed to enhance your security system. With 10TB of storage and four built-in PoE ports, this NVR offers exceptional performance with real-time recording capabilities at up to 8MP resolution. Its advanced H.265 compression technology allows for efficient storage, making it an ideal choice for both personal and professional surveillance needs.
Key Configuration
Model: N4NRV10TB | Real-Time Recording | H.265 Compression | 4K HDMI Output | Ample Storage | Line Crossing Detection
Key Features
- • Capture high-quality video at up to 8MP resolution (4K) @ 30fps.
- • Store up to 2x more footage compared to H.264.
- • Versatile display options with 4K HDMI and VGA outputs.
- • One SATA port supports up to 10TB of storage.
- • Advanced motion detection capabilities.
Installation Notes
255mm x 222mm x 42mm
| Specifications | |
| IP Channels | 4 Channels |
| Harddrive Size | 10TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI), Facial Recognition |
| Resolution | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Compression | H.264/H.265 auto detection (max. 8MP) |
| Bandwidth | 40/64Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 255mm x 222mm x 42mm |
| Voltage | Power per PoE Port Max (802.3at) 30W |
| Power Consumption | ≤ 10W (without HDD) |
| SATA | 1 |
| USB | 2 (USB 2.0) |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | 4-CH IPC |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Video Resolution | Up to 8MP (4K) |
| Recording Frame Rate | 30fps |
| HDMI Output | 4K |
| Storage Capacity | Up to 10TB |
| Built-in PoE Ports | 4 |
| Real-Time Recording | Capture high-quality video at up to 8MP resolution (4K) @ 30fps for crystal-clear images. |
| 4K HDMI Output | Enjoy stunning visuals with a 4K HDMI and an additional VGA monitor output for versatile display options. |
| Ample Storage | One SATA port supports up to 10TB of storage, ensuring you have plenty of space for your recordings. |
| Specification Sheet | |
| PoE Ports | 4 Built-in PoE Ports |
| Storage | 1 SATA port for up to 10TB |
| VGA Output | 1 VGA monitor output |
| Warranty | 5-year limited warranty |
| Compliance | NDAA compliant |
