Speco - N4NRV2TB - 4 Channel Network Video Recorder with 4 Built-In PoE Ports, 2TB
Part number:
Price:
Product Overview
The N4NRV2TB from Speco is a 4 channel network video recorder with 4 built-in PoE ports, 2TB. Speco’s NDAA compliant NRV recorders will take your footage quality supporting up to 8MP cameras @ 30 fps.
Key Configuration
Model: N4NRV2TB | Real time recording up to 8MP resolution (4K) @ 30fps | H.265 compression – Store up to 2x more than H.264 | 4K HDMI output and one VGA monitor output | 1 SATA port for up to 10TB of storage | Line crossing detection
Key Features
- • Real time recording up to 8MP resolution (4K) @ 30fps.
- • H.265 compression – Store up to 2x more than H.264.
- • 4K HDMI output and one VGA monitor output.
- • Remote viewing via web browser or your mobile device.
- • Easy video exporting via USB.
Installation Notes
255mm x 222mm x 42mm
| Specifications | |
| IP Channels | 4 Channels |
| Harddrive Size | 2TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI), Facial Recognition |
| Resolution | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Compression | H.264/H.265 auto detection (max. 8MP) |
| Bandwidth | 40/64Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 255mm x 222mm x 42mm |
| Voltage | Power per PoE Port Max (802.3at) 30W |
| Power Consumption | ≤ 10W (without HDD) |
| SATA | 1 |
| USB | 2 (USB 2.0) |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | 4-CH IPC |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| N4NRV | 1 SATA port for up to 10TB of storage |
| Specification Sheet | |
| Model | N4NRV |
| Video Input - Max. IP Channels | 4 |
| Video Input - IP Camera | H.264/H.265 auto detection (max. 8MP) |
| Video Output - Main Monitor | HDMI (max. 4K) and VGA (max. Full HD) |
| Audio Network Input | 4-CH IPC |
| Recording - Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Recording - Codec | H.264/H.265 (auto detection) |
| Recording - Max Frame Rate per Channel | 8MP @ 30fps |
| Recording - Recording Mode | Analytics/continuous/motion/schedule/manual |
| Recording - Pre-Recording | Max. 5 seconds |
| Search & Playback - Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback - Simultaneous Playback | Max 4-CH |
| Search & Playback - Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback - Playback Resolutions | 1 x 8MP @ 30 FPS, 4 x 1080P @ 30 FPS |
| Search & Playback - Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup - Media | USB drive, network |
| Backup - Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage - HDD Max Capacity of each HDD | 4-CH - 10TB |
| Storage - HDD Internal SATA ports | 1 |
| Storage - USB Rear | 2 (USB 2.0) |
| Alarm - Mode | Manual, motion |
| Alarm - Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F - Input Method | Mouse |
| Network - Network Bandwidth | 40/64Mbps |
| Network - P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network - Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access - Mobile | iOS+/Android™ via Speco Blue App |
| Network Access - Web Viewer | Google Chrome+, Microsoft Edge+, Firefox+ |
| Network Access - VMS/CMS | Speco Blue VMS |
| Network Access - Max. User Access | Max 64 users access |
| Features - Digital Zoom | Live and playback, free size |
| Features - S.M.A.R.T. | Temperature, power on time, bad sectors, and health |
| Smart Analytics (if supported by camera) - People/vehicle detection, video metadata, LPR | 4 |
| Power - PoE Ports | 4 |
| Power - Power per PoE Port Max (802.3at) | 30W |
| Power - Total PoE Power Budget (802.3af/at) | 40W |
| Environment - Operating Humidity | 10% - 90% humidity |
