Speco - N4NRV4TB - 4 Channel Network Video Recorder with 4 Built-In PoE Ports, 4TB
Part number:
Price:
Product Overview
The Speco N4NRV4TB 4 Channel Network Video Recorder is designed for superior surveillance with remarkable features that ensure high-quality video capture and efficient storage. With 4 built-in PoE ports, it simplifies installation while providing real-time recording at an impressive 8MP resolution. Coupled with advanced compression technology, this NVR offers expanded storage capabilities, making it an ideal choice for both commercial and residential security systems.
Key Configuration
Model: N4NRV4TB
Key Features
- • Real-time recording: Enjoy crystal-clear video at up to 8MP resolution (4K) @ 30fps.
- • H.265 compression: Maximize your storage efficiency with H.265 technology.
- • Multiple output options: Connect easily with 4K HDMI output and a VGA monitor output.
- • Ample storage capacity: Features 1 SATA port supporting up to 10TB.
- • Enhanced security analytics: Utilize line crossing detection.
Installation Notes
255mm x 222mm x 42mm
| Specifications | |
| IP Channels | 4 Channels |
| Harddrive Size | 4TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI), Facial Recognition |
| Resolution | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Compression | H.264/H.265 auto detection (max. 8MP) |
| Bandwidth | 40/64Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 255mm x 222mm x 42mm |
| Voltage | Power per PoE Port Max (802.3at) 30W |
| Power Consumption | ≤ 10W (without HDD) |
| SATA | 1 |
| USB | 2 (USB 2.0) |
| Post-alarm Recording | Max. 10 minutes |
| Pre-alarm Recording | Max. 5 seconds |
| Audio | 4-CH IPC |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Built-in PoE Ports | 4 |
| Video Resolution | Up to 8MP (4K) |
| Frame Rate | 30fps |
| HDMI Output | 4K |
| Max Storage Capacity | 10TB |
| Real-time recording | Enjoy crystal-clear video at up to 8MP resolution (4K) @ 30fps, allowing for detailed monitoring of all areas under surveillance. |
| Multiple output options | Connect easily to your display device with 4K HDMI output and a VGA monitor output for versatile viewing options. |
| Ample storage capacity | Features 1 SATA port supporting up to 10TB of additional storage, suitable for extensive recording needs. |
| Specification Sheet | |
| Model | N4NRV |
| Video Input - Max. IP Channels | 4 |
| Video Input - IP Camera | H.264/H.265 auto detection (max. 8MP) |
| Video Output - Main Monitor | HDMI (max. 4K) and VGA (max. Full HD) |
| Audio Network Input | 4-CH IPC |
| Recording - Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Recording - Codec | H.264/H.265 (auto detection) |
| Recording - Max Frame Rate per Channel | 8MP @ 30fps |
| Recording - Recording Mode | Analytics/continuous/motion/schedule/manual |
| Recording - Pre-Recording | Max. 5 seconds |
| Search & Playback - Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback - Simultaneous Playback | Max 4-CH |
| Search & Playback - Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback - Playback Resolutions | 1 x 8MP @ 30 FPS, 4 x 1080P @ 30 FPS |
| Search & Playback - Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup - Media | USB drive, network |
| Backup - Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage - HDD Max Capacity of each HDD | 4-CH - 10TB |
| Storage - HDD Internal SATA ports | 1 |
| Storage - USB Rear | 2 (USB 2.0) |
| Alarm - Mode | Manual, motion |
| Alarm - Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F - Input Method | Mouse |
| Network - Network Bandwidth | 40/64Mbps |
| Network - P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network - Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access - Mobile | iOS+/Android™ via Speco Blue App |
| Network Access - Web Viewer | Google Chrome+, Microsoft Edge+, Firefox+ |
| Network Access - VMS/CMS | Speco Blue VMS |
| Network Access - Max. User Access | Max 64 users access |
| Features - Digital Zoom | Live and playback, free size |
| Features - S.M.A.R.T. | Temperature, power on time, bad sectors, and health |
| Smart Analytics (if supported by camera) - People/vehicle detection, video metadata, LPR | 4 |
| Power - PoE Ports | 4 |
| Power - Power per PoE Port Max (802.3at) | 30W |
| Power - Total PoE Power Budget (802.3af/at) | 40W |
| Environment - Operating Humidity | 10% - 90% humidity |
