Speco - N64NR160TB - 64 Channel 4K H.265 NVR with Analytics, 160TB
Part number:
Price:
Product Overview
The Speco N64NR160TB is a cutting-edge 64 channel 4K H.265 NVR designed to maximize performance and storage capabilities while providing advanced analytics. 16MP (8K) H.265 Network Video Recorder IP
Key Configuration
Model: N64NR160TB
Key Features
- • Real-time recording up to 16MP resolution (8K) at 30fps.
- • H.265 compression - Store up to 2x more than H.264!.
- • 4K HDMI out and one VGA monitor output, additional storage via 2 eSATA ports.
- • Search and be alerted to analytic events.
- • Smart Search - Specify a region on the camera view and search on changes in that area.
Installation Notes
445mm x 436mm x 90mm (17.5” x 17.1” x 3.5”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 64 Channels |
| Harddrive Size | 160TB |
| Protocols | speco Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI) |
| Resolution | 16MP/12MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Compression | H.264/H.265 |
| Bandwidth | 640Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 445mm x 436mm x 90mm (17.5” x 17.1” x 3.5”) |
| USB | Front 1 (USB 2.0), Rear 1 (USB 2.0) |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Product Type | 64 Channel NVR |
| Max Resolution | 16MP (8K) |
| Frame Rate | 30fps |
| Video Outputs | 4K HDMI, VGA |
| Networking | DDNS, P2P |
| Compliance | NDAA Compliant |
| Video Exporting | USB |
| Real-time recording | Captures video at up to 16MP resolution (8K) at 30fps for crystal-clear images. |
| Multiple outputs | 4K HDMI and VGA outputs allow for flexible monitor setups and enhanced viewing experiences. |
| Easy video exporting | Plug and play USB functionality for quick file transfers. |
| Technical Specifications Video Recorder | |
| Model | NR Series |
| Video Input Max. IP Channels | 64 |
| Video Input IP Camera | H.264/H.265 auto detection (max. 16MP) |
| Video Output Resolutions | HDMI 1: 7680x4320 @ 60, 7680x4320 @ 30, 3840x2160 @ 60, 3840x2160 @ 30, 1920x1080, 1280x1024, 1024x768 (when the resolution of HDMI 1 output is 8K, HDMI 2 is unavailable and the maximum resolution of HDMI 3 output is 1920x1080) HDMI 2: 3840x2160 @ 60, 3840x2160 @ 30, 1920x1080, 1280x1024, 1024x768 HDMI 3: 3840x2160 @ 60, 3840x2160 @ 30, 1920x1080, 1280x1024, 1024x768 HDMI 4: 1920x1080, 1280x1024, 1024x768 |
| Video Output Max. Live View Channels | HDMI 1: 64 HDMI 2: 36 HDMI 3: 16 HDMI 4: 16 |
| Audio Network Input | 64-CH IPC audio input |
| Audio 2-way Audio | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/12MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Max Frame Rate per Channel | Any resolution @ 30fps |
| Recording Recording Mode | AI/continuous/motion/sensor/schedule/manual |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max 16-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Backup Media | USB drive, USB portable HDD, network |
| Backup Format | JPG, AVI, ZIP (player+proprietary data) |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 8 |
| Storage USB Front | 1 (USB 2.0) |
| Storage USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Storage Raid Type | RAID 0, 1, 5, 6, 10 |
| Storage eSata | 2 |
| Alarm Mode | Manual, sensor, motion, exception, AI |
| Alarm Input | 16-CH local |
| Alarm Output | 4-CH local |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 640Mbps |
| Network P2P/Dynamic DNS | Free US-based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Dual Network Card | Yes |
| Network LAN 1 | Recorder: RJ45 10/100/1000Mbps |
| Network LAN 2 | Cameras: RJ45 10/100/1000Mbps |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome*, Microsoft Edge*, Safari*, FireFox*, Windows® IE |
| Network Access VMS | SecureGuard®, Speco Blue VMS |
| Network Access Max. User Access | Max. 128 users online (web client) |
| Features Digital Zoom | Live and playback, free size |
| Features Fisheye Dewarping* | Yes |
| Features S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) | Temperature, power on time, bad sectors and health |
| Smart Analytics People / Vehicle Detection | Line crossing, intrusion, people counting |
| Smart Analytics Facial Recognition | Store up to 10,000 face images; up to 16-CH for event trigger; face Search up to 64-CH |
| Smart Analytics LPR | LPR on all 64-CH, store up to 50,000 license plate images |
| Smart Analytics Others | Object abandoned/missing, trip wire |
| Power Power Consumption | ≤ 50W (without HDD) |
