Speco - N64NR30TB - 64 Channel 4K H.265 Network Video Recorder with Smart Analytics, 30TB
Part number:
Price:
Product Overview
The N64NR30TB from Speco is a powerful 64 Channel 4K H.265 Network Video Recorder designed to meet the needs of both home and business surveillance. With its impressive 30TB storage capacity and advanced smart analytics, this DVR ensures high-quality video recording, easy management, and efficient utilization of storage space.
Key Configuration
Model: N64NR30TB
Key Features
- • Real-time recording up to 8MP resolution (4K) at 30fps.
- • H.265 compression - Store up to 2x more than H.264.
- • 4K HDMI out and one VGA monitor output, additional storage via 2 eSATA ports.
- • 8 SATA ports for up to 112TB of storage max.
- • Object and line crossing detection and alerts.
Installation Notes
430mm x 453mm x 89mm (16.9" x 17.8" x 3.5")
| Specifications | |
| IP Channels | 64 Channels |
| Harddrive Size | 30TB |
| Protocols | Onvif Protocols |
| Features | Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.265 Compression, Supports PTZ Control, Supports the Full HD Output (HDMI), Two-way Audio |
| Resolution | 8MP/5MP/4MP/3MP/1080P/720P; Up to 8MP (4K) (Details tab) |
| Compression | H.265 |
| Bandwidth | 320Mbps |
| Operating temperature | -4°F ~ 122°F(-10°C ~ 50°C) |
| Dimensions | 430mm x 453mm x 89mm (16.9" x 17.8" x 3.5") |
| SATA | 8 |
| USB | Front 1 (USB 2.0), Rear 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Audio | 2-Way Audio |
| Frame Rate/Camera | Any Resolution @30fps |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| Two Way Audio | Yes |
| Supports PTZ Control | Yes |
| H.265 Compression | Yes |
| Details | |
| Video Output | 4K HDMI, VGA |
| Storage Capacity | 30TB Built-in, Expandable up to 112TB |
| Audio Support | 2-way audio communication |
| Real-time recording | Captures video at up to 8MP resolution (4K) at 30fps, providing crystal clear images for reliable surveillance. |
| Multiple video outputs | Features 4K HDMI out and one VGA monitor output for versatile viewing options. |
| Expandable storage | Equipped with 8 SATA ports, supporting up to a maximum of 112TB storage, ensuring extensive recording capabilities. |
| Easy video export | Quick exporting via USB makes it simple to share or archive footage. |
| Simultaneous output | Offers HDMI and VGA video output simultaneously to support different monitoring setups. |
| Onvif compatible | Works seamlessly with a vast range of ONVIF Profile S conformant cameras, enhancing system versatility. |
| Technical Specifications Video Recorder | |
| Model | N64NR |
| Video Input | Max. IP Channels: 64 |
| Audio Network Input | 64-CH IPC audio input |
| Audio 2-way Audio | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/12MP/8MP/5MP/4MP/3MP/1080P/720P/960H/D1/CIF |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Recording Mode | AI/continuous/motion/sensor/schedule/manual |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max 16-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Backup Media | USB drive, USB portable HDD, network |
| Backup Format | JPG, AVI, ZIP (player+proprietary data) |
| Storage HDD Max Capacity of each HDD | 20TB |
| Storage HDD Internal SATA ports | 8 |
| Storage USB Front | 1 (USB 2.0) |
| Storage USB Rear | 2 USBs: 1 USB 2.0, 1 USB 3.0 |
| Storage Raid Type | RAID 0, 1, 5, 6, 10 |
| Storage eSata | 2 |
| Alarm Mode | Manual, sensor, motion, exception, AI |
| Alarm Input | 16-CH local |
| Alarm Output | 4-CH local |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 640Mbps |
| Network P2P/Dynamic DNS | Free US-based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Dual Network Card | Yes |
| Network LAN 1 | Recorder: RJ45 10/100/1000Mbps |
| Network LAN 2 | Cameras: RJ45 10/100/1000Mbps |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome*, Microsoft Edge*, Safari*, FireFox*, Windows® IE |
| Network Access VMS | SecureGuard®, Speco Blue VMS |
| Network Access Max. User Access | Max. 128 users online (web client) |
| Features Digital Zoom | Live and playback, free size |
| Features Fisheye Dewarping* | Yes |
| Features S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) | Temperature, power on time, bad sectors and health |
| Smart Analytics People / Vehicle Detection | Line crossing, intrusion, people counting |
| Smart Analytics Facial Recognition | Store up to 10,000 face images; up to 16-CH for event trigger; face Search up to 64-CH |
| Smart Analytics LPR | LPR on all 64-CH, store up to 50,000 license plate images |
| Smart Analytics Others | Object abandoned/missing, trip wire |
| Power Power Consumption | ≤ 50W (without HDD) |
| Environment Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
