Speco - N8NRV - 8 Channel Network Video Recorder with 8 Built-In PoE Ports
Part number:
Price:
Product Overview
Network Video Recorder 8-Channel 8 Built-in PoE Ports Speco’s NDAA compliant NRV recorders, will take your footage quality supporting up to 8MP cameras @ 30 fps.
Key Configuration
Model: N8NRV
Key Features
- • Supported Analytics: Line Crossing, Region Intrusion, Plate Detection, Face Detection, Video Metadata, Loitering, Illegal parking, Heat Map, Target counting by line and area, Tampering, Object abandoned, People counting, Crowd density, People gathering, Fire detection and Temperature detection.
- • Real time recording up to 8MP resolution (4K) @ 30fps.
- • H.265 compression – Store up to 2x more than H.264!.
- • 4K HDMI output and one VGA monitor output.
- • N8NRV: 1 SATA port for up to 10TB of storage.
Installation Notes
255mm x 222mm x 42mm
| Technical Specifications | |
| Video Input Max. IP Channels | 8 |
| Video Input IP Camera | H.264/H.265 auto detection (max. 8MP) |
| Video Output Main Monitor | HDMI (max. 4K) and VGA (max. Full HD) |
| Audio Network Input | 8-CH IPC |
| Recording Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Max Frame Rate per Channel | 8MP @ 30fps |
| Recording Recording Mode | Analytics/continuous/motion/schedule/manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max 8-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Resolutions | 1 x 8MP @ 30 FPS, 4 x 1080P @ 30 FPS |
| Search & Playback Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage HDD Max Capacity of each HDD | 8-CH - 10TB |
| Storage HDD Internal SATA ports | 1 |
| Storage USB Rear | 2 (USB 2.0) |
| Alarm Mode | Manual, motion |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | Mouse |
| Network Network Bandwidth | 64Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS+/Android™ via Speco Blue App |
| Network Access Web Viewer | Google Chrome+, Microsoft Edge+, Firefox+ |
| Network Access VMS/CMS | Speco Blue VMS |
| Network Access Max. User Access | Max 64 users access |
| Features Digital Zoom | Live and playback, free size |
| Features S.M.A.R.T. | Temperature, power on time, bad sectors, and health |
| Smart Analytics (if supported by camera) People/vehicle detection, video metadata, LPR | 8 |
| Power Power consumption | ≤ 10W (without HDD) |
| Power PoE Ports | 8 |
| Power Power per PoE Port Max (802.3at) | 30W |
| Power Total PoE Power Budget (802.3af/at) | 72W |
| Environment Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Environment Operating Humidity | 10% - 90% humidity |
