Speco - N8NRV2TB - 8 Channel Network Video Recorder with 8 Built-In PoE Ports, 2TB
Part number:
Price:
Product Overview
The Speco N8NRV2TB is an advanced 8 Channel Network Video Recorder that provides powerful surveillance capabilities with its built-in PoE ports and ample storage. Speco’s NDAA compliant NRV recorders, will take your footage quality supporting up to 8MP cameras @ 30 fps.
Key Configuration
Model: N8NRV2TB | 8 Channel | 2TB Storage | Expandable to 10TB
Key Features
- • Real-time recording up to 8MP resolution (4K) @ 30fps.
- • H.265 compression – Store up to 2x more than H.264.
- • 4K HDMI output and one VGA monitor output.
- • Line crossing detection.
- • N4NRV: 1 SATA port for up to 10TB of storage N8NRV: 1 SATA port for up to 10TB of storage.
Installation Notes
255mm x 222mm x 42mm
| Specification | Value |
|---|---|
| General | |
| Model | N8NRV |
| Installed HDD Capacity | 2TB |
| Dimensions | 255mm × 222mm × 42mm |
| Video | |
| Max. IP Channels | 8 |
| IP Camera Compatibility | H.264/H.265 auto detection; max. 8MP |
| Main Monitor Outputs | HDMI (max. 4K), VGA (max. Full HD) |
| Audio | |
| Network Audio Input | 8-CH IPC |
| Recording | |
| Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF — “DI” needs verification; possibly “D1” |
| Recording Codec | H.264/H.265 (auto detection) |
| Max. Frame Rate per Channel | 8MP @ 30fps |
| Recording Mode | Analytics, continuous, motion, schedule, manual |
| Pre-Recording | Max. 5 seconds |
| Post-Alarm Recording | Max. 10 minutes |
| Search & Playback | |
| Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Simultaneous Playback | Max. 8-CH |
| Playback Resolutions | 1 × 8MP @ 30fps; 4 × 1080P @ 30fps |
| Smart Search | Color-coded recording periods indicating different recording events |
| Playback Functions | Play, pause, fast forward, rewind |
| Digital Zoom | Live and playback; free size |
| Backup | |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage | |
| Internal SATA Ports | 1 |
| Max. HDD Capacity | 10TB |
| USB Ports | Rear: 2 × USB 2.0 |
| S.M.A.R.T. | Temperature, power-on time, bad sectors, drive health |
| Alarm | |
| Alarm Mode | Manual, motion |
| Alarm Linkage | Record, snapshot, preset, email notification, pop-up window |
| User Interface | |
| Input Method | Mouse |
| Network | |
| Network Bandwidth | 64Mbps |
| P2P / Dynamic DNS | Free US-based Speco P2P and DDNS service |
| Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Other Protocol Support | “speco Protocols” — specific protocols need clarification |
| Network Access | |
| Mobile Access | iOS/Android via Speco Blue App |
| Web Viewer | Google Chrome, Microsoft Edge, Firefox |
| VMS/CMS | Speco Blue VMS |
| Max. User Access | Max. 64 users |
| Smart Analytics | |
| People / Vehicle Detection, Video Metadata, LPR | 8 channels, if supported by camera |
| Facial Recognition | Listed in Features; support needs verification against the datasheet |
| Power | |
| Power Consumption | ≤10W (without HDD) |
| PoE Ports | 8 |
| Max. Power per PoE Port | 30W (802.3at) |
| Total PoE Power Budget | 72W (802.3af/at) |
| Environment | |
| Operating Temperature | −10°C to 50°C (14°F to 122°F) |
| Operating Humidity | 10%–90% |
