Speco - N8NRV4TB - 8 Channel Network Video Recorder with 8 Built-In PoE Ports, 4TB
Part number:
Price:
Product Overview
The N8NRV4TB from Speco is an 8 channel network video recorder with 8 built-in PoE ports, supporting up to 8MP cameras at 30 fps. Features include H.265 compression, 4K HDMI output, and smart search capabilities. Speco’s NDAA compliant NRV recorders, will take your footage quality supporting up to 8MP cameras @ 30 fps.
Key Configuration
Model: N8NRV4TB
Key Features
- • Real time recording up to 8MP resolution (4K) @ 30fps.
- • H.265 compression – Store up to 2x more than H.264!.
- • 4K HDMI output and one VGA monitor output.
- • N8NRV: 1 SATA port for up to 10TB of storage.
- • Line crossing detection.
Installation Notes
255mm x 222mm x 42mm
| Specification | Value |
|---|---|
| General | |
| Model | N8NRV |
| Installed HDD Capacity | 4TB |
| Dimensions | 255mm × 222mm × 42mm |
| Video | |
| Max. IP Channels | 8 |
| IP Camera Compatibility | H.264/H.265 auto detection; max. 8MP |
| Main Monitor Outputs | HDMI (max. 4K), VGA (max. Full HD) |
| Audio | |
| Network Audio Input | 8-CH IPC |
| Recording | |
| Encoding Resolutions | 8MP/6MP/4MP/3MP/1080P/720P/960H/DI/CIF |
| Recording Codec | H.264/H.265 (auto detection) |
| Max. Frame Rate per Channel | 8MP @ 30fps |
| Recording Mode | Analytics, continuous, motion, schedule, manual |
| Pre-Recording | Max. 5 seconds |
| Post-Alarm Recording | Max. 10 minutes |
| Search & Playback | |
| Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Simultaneous Playback | Max. 8-CH |
| Playback Resolutions | 1 × 8MP @ 30fps; 4 × 1080P @ 30fps |
| Smart Search | Color-coded recording periods indicating different recording events |
| Playback Functions | Play, pause, fast forward, rewind, etc. |
| Digital Zoom | Live and playback; free size |
| Backup | |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (includes player) |
| Storage | |
| Internal SATA Ports | 1 |
| Max. HDD Capacity | 10TB |
| USB Ports | Rear: 2 × USB 2.0 |
| S.M.A.R.T. | Temperature, power-on time, bad sectors, drive health |
| Alarm | |
| Alarm Mode | Manual, motion |
| Alarm Linkage | Record, snapshot, preset, email notification, pop-up window |
| User Interface | |
| Input Method | Mouse |
| Network | |
| Network Bandwidth | 64Mbps |
| P2P / Dynamic DNS | Free US-based Speco P2P and DDNS service |
| Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Other Protocol Support | “speco Protocols” |
| Network Access | |
| Mobile Access | iOS/Android via Speco Blue App |
| Web Viewer | Google Chrome, Microsoft Edge, Firefox |
| VMS/CMS | Speco Blue VMS |
| Max. User Access | Max. 64 users |
| Smart Analytics | |
| People / Vehicle Detection, Video Metadata, LPR | 8 channels, if supported by camera |
| Facial Recognition | Listed in Features; |
| Power | |
| Power Consumption | ≤10W (without HDD) |
| PoE Ports | 8 |
| Max. Power per PoE Port | 30W (802.3at) |
| Total PoE Power Budget | 72W (802.3af/at) |
| Environment | |
| Operating Temperature | −10°C to 50°C (14°F to 122°F) |
| Operating Humidity | 10%–90% |
Name
Description
Size
Downloads
File
Specification Sheet
1.2mb
