Speco - N8NRX - 8K H.265 NVR with Facial Recognition and Smart Analytics
Part number:
Price:
Product Overview
8 Channel Facial Recognition NVR with 8 Built-In PoE Ports
Key Configuration
Model: N8NRX
Key Features
- • Real time recording up to 16MP resolution (8K) at 30fps.
- • H.265 compression – Store up to 2x more than H.264!.
- • 4K HDMI out and one VGA monitor output.
- • N8NRX: 1 SATA port for up to 20TB of storage max.
- • N16NRX: 2 SATA ports for up to 40TB of storage max.
Installation Notes
300mm x 249mm x 45mm (11.8" x 9.8" x 2.0")
| Full Specifications | |
| Terabyte Size | 12TB, 16TB, 2TB, 4TB, 6TB, 8TB |
| Technical Specification NVR Video Recorder | |
| Model | NRX |
| Video Input Max. IP Channels | 8 |
| Video Input IP Camera | H.265/H.264 auto detection (max. 16MP) |
| Video Output Main Monitor | HDMI (max. 4K) and VGA (max. full HD) |
| Audio Network Input | 8-CH IPC audio input |
| Audio Local Input | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Recording Codec | H.264/H.265 (auto detection) |
| Recording Max Frame Rate per Channel | 16MP @ 30fps |
| Recording Recording Mode | Analytics/continuous/motion/sensor/schedule/manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max. 8-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Functions | Play, pause, fast forward, rewind, digital zoom, etc. |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, proprietary format (player included) |
| Storage HDD Max Capacity of each HDD | 40TB |
| Storage HDD Internal SATA ports | 1 |
| Storage USB Front | 1 (USB 2.0) |
| Storage USB Rear | 1 USB 3.0 1 USB 2.0 |
| Alarm Mode | Manual, sensor, motion, exception, intelligence |
| Alarm Input | 8-CH local |
| Alarm Output | 4-CH local |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 160Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome®, Microsoft Edge®, Firefox®, Safari® |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard® |
| Network Access Max. User Access | Max 10 users online (web client) |
| Features Digital Zoom | Live and playback, free size |
| Features Fisheye Dewraping* | Yes |
| Features S.M.A.R.T (Self-Monitoring, Analysis & Reporting Technology) | Temperature, power on time, bad sectors, and health |
| Smart Analytics People/Vehicle Detection | Line crossing and intrusion |
| Smart Analytics Facial Recognition | Face search up to 8-CH (N8NRX) and up to 16-CH (N16NRX) Face recognition trigger event up to 6-CH |
| Smart Analytics LPR | 8-CH |
| Power Power Consumption | ≤ 15W (without HDD) |
| Power PoE Ports | 8 |
| Power Power per PoE Port Max (802.3at) | 30W |
| Power Total PoE Power Budget (802.3af/at) | 80W |
| Environment Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Environment Operating Humidity | 10% - 90% humidity |
| Dimensions Unit | 300mm x 249mm x 45mm (11.8" x 9.8" x 2.0") |
