Speco - N8NRX20TB - 8K H.265 NVR with Facial Recognition and Smart Analytics with, 20TB
Part number:
Price:
Product Overview
The Speco N8NRX20TB is an advanced 8K H.265 NVR featuring cutting-edge facial recognition and smart analytics, making it the ideal choice for enhancing surveillance quality. With Speco’s NDAA compliant NRX recorder, you will take your footage quality to the next level now supporting up to 16MP cameras @ 30 fps.
Key Configuration
Model: N8NRX20TB
Key Features
- • Real-time Recording: Captures footage in stunning 8K resolution at 30fps for superior clarity.
- • Advanced Compression: H.265 video compression allows you to store up to 2x more footage than traditional H.264.
- • Multiple Output Options: Equipped with 4K HDMI out and VGA output for versatile display capabilities.
- • High Storage Capacity: Single SATA port supports up to 20TB, ensuring ample space for recorded footage.
- • Smart Analytics: Features like facial recognition and object detection enhance security and monitoring efficiency.
Installation Notes
380mm x 268mm x 45mm (15.0” x 10.6” x 2.0”)
| Specifications | |
| IP Channels | 8 Channels |
| Harddrive Size | 20TB |
| Protocols | speco Protocols |
| Features | Compression Supported, DDNS Functionality, H.264 Compression, Supports the Full HD Output (HDMI) |
| Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P; Up to 16MP (8K) (Details tab) |
| Compression | H.265 |
| Bandwidth | 192Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 380mm x 268mm x 45mm (15.0” x 10.6” x 2.0”) |
| Power Consumption | ≤ 15W (without HDD) |
| SATA | 1 |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | 16-CH IPC audio input |
| Frame Rate/Camera | 16MP @ 30fps |
| DDNS Functionality | Yes |
| HDMI Output (720p/1080p) | Yes |
| H.264 Compression | Yes |
| Details | |
| Storage Capacity | 20TB (1 SATA port) |
| Video Outputs | 4K HDMI, VGA |
| Export Options | USB video export |
| Warranty | 5 years |
| Real-time Recording | Captures footage in stunning 8K resolution at 30fps for superior clarity. |
| Advanced Compression | H.265 video compression allows you to store up to 2x more footage than traditional H.264. |
| Multiple Output Options | Equipped with 4K HDMI out and VGA output for versatile display capabilities. |
| High Storage Capacity | Single SATA port supports up to 20TB, ensuring ample space for recorded footage. |
| Simple Video Export | Hassle-free video exporting via USB for easy sharing and storage. |
| Technical Specification | |
| Model | N8NRX |
| Video | Input Max. IP Channels 8 |
| Recording | Encoding Resolutions 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Search & Playback | Search EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Backup | Media USB drive, network |
| Storage | HDD Max Capacity of each HDD 40TB |
| Alarm | Mode Manual, sensor, motion, exception, intelligence |
| User I/F | Input Method IR remote, mouse |
| Network | Network Bandwidth 160Mbps |
| Network Access | Mobile iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Smart Analytics | People/Vehicle Detection Line crossing and intrusion |
| Power | Power Consumption ≤ 15W (without HDD) |
| Environment | Operating Temperature 14°F to 122°F (-10°C to 50°C) |
