Speco - N8WNRXM20TB - 8 Channel 8K Network Video Recorder with 8 Plug & Play Ports, 20TB
Part number:
Price:
Product Overview
Speco’s NDAA compliant WNRX and WNRXM recorders will take your footage quality to the next level supporting up to 16MP cameras at 30 fps.
Key Configuration
Model: N8WNRXM20TB | 8 Channels | 20TB Storage
Key Features
- • Real-time Recording up to 16MP (8K) at 30fps.
- • H.265 Compression for storage efficiency.
- • 4K HDMI and VGA Outputs.
- • Facial Recognition and Comparison.
- • Supports Remote Access via web and mobile.
Installation Notes
387mm x 298mm x 89mm (15.25” x 11.75” x 3.5”)
| Specifications | |
| NDAA | Compliant |
| IP Channels | 8 Channels |
| Harddrive Size | 20TB |
| Protocols | speco Protocols |
| Features | AI Analytics, Alarm Notification by E-mail, Audio, Compression Supported, DDNS Functionality, H.264 Compression, H.265 Compression, Supports the Full HD Output (HDMI), Facial Recognition |
| Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Compression | H.265/H.264 (auto detection) |
| Bandwidth | 160Mbps |
| Operating temperature | 14°F to 122°F (-10°C to 50°C ) |
| Dimensions | 387mm x 298mm x 89mm (15.25” x 11.75” x 3.5”) |
| Power Consumption | ≤ 15W (without HDD) |
| SATA | 1 |
| USB | 1 USB 2.0, 1 USB 3.0 |
| Audio | RCAx1 |
| Frame Rate/Camera | 16MP @ 30fps |
| Compression Supported | Yes |
| Alarm Notification by E-mail | Yes |
| DDNS Functionality | Yes |
| Supports the Full HD Output (HDMI) | Yes |
| H.264 Compression | Yes |
| H.265 Compression | Yes |
| Details | |
| Frame Rate | 30 fps |
| Video Outputs | 4K HDMI, VGA |
| Storage Type | SATA |
| Max Storage Capacity | 16TB |
| Easy Export | Via USB |
| Real-time Recording | up to 16MP resolution (8K) at 30fps ensures crystal-clear image quality and smooth playback. |
| Multiple Outputs | 4K HDMI and VGA monitor output allow flexible display options for monitoring live footage. |
| Storage Capacity | N8WNRX & N8WNRXM come with 1 SATA port for up to 16TB of maximum storage capacity, accommodating extensive recording needs. |
| Easy Exporting | Simple video exporting via USB for quick file transfers and sharing. |
| Specification Sheet | |
| Model | WNRX / WNRXM Series |
| Video Input | Max. IP Channels 8 |
| Audio Network Input | 8-CH IPC audio input |
| Audio Local Input | RCAx1 |
| Audio Local Output | RCAx1 |
| Recording Encoding Resolutions | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P |
| Recording Codec | H.265/H.264 (auto detection) |
| Recording Max Frame Rate per Channel | 16MP @ 30fps |
| Recording Mode | Analytics/continuous/motion/sensor/schedule/manual |
| Recording Pre-Recording | Max. 5 seconds |
| Recording Post Recording | Max. 10 minutes |
| Search & Playback Search | EZ search, motion, specific date/time, event, museum, bookmarks, snapshots, log |
| Search & Playback Simultaneous Playback | Max. 8-CH |
| Search & Playback Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| Search & Playback Playback Functions | Play, pause, FF, FB, digital zoom, etc. |
| Backup Media | USB drive, network |
| Backup Format | MP4, JPG, AVI, RPAS, ZIP (player + proprietary data) |
| Storage HDD Max Capacity of each HDD | 16TB |
| Storage HDD Internal SATA ports | 1 |
| Storage USB Front | 1 (USB 2.0) |
| Storage USB Rear | 1 USB 2.0, 1 USB 3.0 |
| Alarm Mode | Manual, sensor, motion, exception, intelligence |
| Alarm Input | 8-CH local |
| Alarm Output | 4-CH local |
| Alarm Linkage | Record/snapshot/preset/email/pop-up window |
| User I/F Input Method | IR remote, mouse |
| Network Network Bandwidth | 160Mbps |
| Network P2P/Dynamic DNS | Free US-Based Speco P2P and DDNS service |
| Network Network Protocols | TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Network Access Mobile | iOS*/Android™ via Speco Blue App, SecureGuard® Client |
| Network Access Web Viewer | Google Chrome*, Microsoft Edge*, Firefox*, Safari* |
| Network Access VMS/CMS | Speco Blue VMS, SecureGuard* |
| Network Access Max. User Access | Max. 10 users online (web client) |
| Features Digital Zoom | Live and playback, free size |
| Features S.M.A.R.T. (Self-Monitoring, Analysis, & Reporting Technology) | Temperature, power on time, bad sectors, and health |
| Smart Analytics People/Vehicle Detection | Line crossing and intrusion |
| Smart Analytics Facial Recognition | Face search up to 8-CH (N8NRX) and up to 16-CH, (N16NRX) Face recognition trigger event up to 6-CH |
| Smart Analytics LPR | 8-CH |
| Power PoE Ports | 8 |
| Power Power per PoE Port Max (802.3at) | 30W |
| Power Total PoE Power Budget (802.3af/at) | 80W |
| Environment Operating Humidity | 10% - 90% humidity |
