Speco - SGBRIDGE1TB - Cloud Bridge with SecureGuard Remote Web Browser Access, 1TB
Part number:
Price:
Product Overview
The Speco SGBRIDGE1TB Cloud Bridge with SecureGuard offers an innovative solution for secure video storage and remote access. With 1TB of memory, it provides ample space for multiple channel recordings, ensuring you never lose important footage. Easy to use with any Speco DVRs, NVRs, or IP cameras, it facilitates effortless remote viewing via the SecureGuard Client on desktops and mobile devices, making it perfect for users who need flexibility and security in their surveillance solutions.
Key Configuration
Model: SGBRIDGE1TB
Key Features
- • 1TB of Storage.
- • Free Software Updates.
- • Compatibility: Works seamlessly with Speco’s DVRs, NVRs, and IP cameras.
- • Linux Based Platform.
- • Global Connectivity: Stay connected anywhere in the world with Speco’s Free DDNS service.
| General | |
| Product Model | SGBRIDGE1TB |
| Product Type | SecureGuard Bridge |
| Maximum Cameras Supported | Up to 32 cameras, depending on camera configuration |
| Supported Resolution | Up to 8MP (4K) |
| Operating System | Linux |
| Software Updates | Free software updates |
| Camera Compatibility | Compatible with Speco DVRs, NVRs, and IP cameras |
| NDAA Compliance | Compliant with NDAA Section 889 Part B guidelines |
| System Hardware | |
| CPU | Intel Celeron |
| Memory | 8GB |
| Operating System Drive | 128GB SSD |
| Network Interfaces | 2 × Gigabit Ethernet |
| Video Outputs | 1 × HDMI 1 × VGA |
| Storage | |
| Storage Configuration | 1TB total storage configuration |
| Available Embedded Storage | 116GB |
| Additional Storage | 875GB |
| Video Buffer | |
| 1MP Cameras | Up to 32 cameras for 1 day on-premises |
| 2MP Cameras | Up to 32 cameras for 1 day on-premises |
| 4MP Cameras | Up to 32 cameras for 1 day on-premises |
| 5MP Cameras | Up to 25 cameras for 1 day on-premises |
| 8MP Cameras | Up to 18 cameras for 1 day on-premises |
| Interfaces | |
| USB Ports | 2 × USB 2.0 2 × USB 3.0 |
| Serial Ports | 2 |
| Video Output Ports | 1 × HDMI 1 × VGA |
| Network and Access | |
| Remote Access | SecureGuard VMS Client and SecureGuard CMS for PC and Mac |
| Mobile Access | SecureGuard Client app for iOS and Android |
| DDNS Service | Free Speco DDNS service |
| Client Access | Multi-client access |
| Installation Options | Surface-mounted or wall-mounted using VESA pattern |
| Physical and Environmental | |
| Dimensions | 5.35" (L) × 5.05" (W) × 1.55" (H) |
| Weight | 1.5lbs |
| Operating Temperature | 32°F to 104°F |
| Non-Operating Temperature | -4°F to 140°F |
| Operating Relative Humidity | 90% at 104°F, non-condensing |
| Power | |
| Input Voltage | 100-240VAC |
| Adapter Type | 12VDC, 3A |
