Product Overview
Two-way audio communication over IP networks. SIP & Onvif protocol compatible. Echo Cancellation, Automatic Gain Control, Noise Reduction. PoE Power supply, 2M Pixels Camera. SD Card Slot, Stable Alloy Shell. Solid and durable, easy installation. Smart IP Video Intercom
Key Configuration
Model: SPIPIC
Key Features
- • Two-way audio communication over IP networks.
- • SIP & Onvif protocol compatible.
- • Echo Cancellation.
- • Automatic Gain Control.
- • Noise Reduction.
Installation Notes
3.5in x 3.5in x 1.3in
| Audio Specifications | |
| Decoding | OPUS 48K, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
| Video Specifications | |
| Video codec | H.264 |
| Video resolution | Main stream 1080P and 720P, Sub stream D1 and CIF |
| Network Specifications | |
| Security | Password protection, IP address filtering, Digest authentication, User access log, firewall |
| Network Protocol | SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP |
| Network Interface | 10/100 Base-TX, RJ45 |
| VoIP | Support SIP protocol for intergration with VoIP systems, integrated with SIP/PBX. Support SIP features: secondary/background SIP server, IPv4 (IPv6 futhur). Support codecs: G711U, G711A, GSM, MP3, WAV. |
| Other Specifications | |
| Material | Alloy panel Metal back cover |
| Power Supply | PoE or DC 12V |
| Interface | Interface 1* IO input, 1* IO output, 1* Relay (NO/COM/NC) |
| Dimensions | 3.5in x 3.5in x 1.3in |
| Weight | 0.63 pounds |
| Languages | English |
Name
Description
Size
Downloads
File
User Manual
2.2mb
File
Quick Start Guide
0.7mb
File
Specification Sheet
0.4mb
