Speco - SXP600 - Solar Powered Panel with Mounting Hardware
Part number:
Price:
Product Overview
Solar Powered Panel with Mounting Hardware (6) 100W solar panels, enclosure, charge controller, PoE switch SIM card not included Network Operator Certifications: AT&T®, T-Mobile®, Verizon®
Key Configuration
Model: SXP600 | 6) 100W solar panels | enclosure | charge controller | PoE switch
Key Features
- • Solar panel and mounting hardware included.
- • Weather-proof aluminum enclosure and mounting hardware included.
- • Lockable wing-knob; locks with pad lock (pad lock not included).
- • Hardwired PoE switch, converters, charging equipment, and are self-contained and safeguarded against environmental factors and tampering.
- • Battery capacity of up to 4 x 100 Ah batteries.
Installation Notes
40"(L) x 27"(W)
| Solar Panel Specifications | |
| Number of Panels | (6) 100W |
| Individual Panel Dimensions | 40"(L) x 27"(W) |
| Panel Weight | 120 lbs. |
| Recommended Pole Size | 3" - 6" schedule 40 rigid metal or stronger (straps not included) |
| Wind Rating | 100 mph |
| Output Voltage | 24VDC |
| Solar Charge Controller | Advanced charge control with max power point tracking (MPPT) algorithm |
| Enclosure Specifications | |
| Enclosure Size | 32"(H) × 24"(W) × 16"(D) |
| Battery Capacity | (4) 100Ah batteries (not included) |
| 100Ah Battery Size* | 9.2"(H) × 12.3"(W) × 6.7"(D) |
| Enclosure Weight | 38 lbs. |
| Material | Aluminum |
| Operating Temperature | -40°F - 140°F |
| Remaining Wattage for Camera Use | |
| Zone 1 | 85 |
| Zone 2 | 70 |
| Zone 3 | 52 |
| Zone 4 | 34 |
| Zone 5 | 16 |
