TRENDnet - TEG-10GBS10D2 - 10G SFP+ Dual Wavelength Single Mode LC Module (10km)

Product Overview

The TRENDnet TEG-10GBS10D2 is a 10G SFP+ dual wavelength single mode LC module designed for long-distance BiDi fiber network connections. It supports data rates up to 10.31 Gbps over distances up to 10 km and is intended for use in standard SFP+ ports on compatible switches and fiber converters.

Key Configuration

10G SFP+ BiDi single mode fiber module with simplex LC optical interface. Supports transmission distances up to 10 km / 6.21 mi. Transmit wavelength: 1270 nm; receive wavelength: 1330 nm

Key Features

• • Supports high-speed data rates up to 10.31 Gbps
• • Uses single mode fiber for reliable long-distance network applications
• • Features a simplex LC optical interface for BiDi fiber connectivity
• • Includes Digital Diagnostics Monitoring (DDM) support
• • NDAA / TAA compliant for U.S. and Canada deployments

Technical Context

This BiDi SFP+ module transmits at 1270 nm and receives at 1330 nm over a single fiber strand, reducing fiber usage compared with duplex connections. It must be paired with the TEG-10GBS10D3 module, which uses the complementary transmit and receive wavelengths.

Installation Notes

The TEG-10GBS10D2 is compatible with standard SFP+ ports on supported network switches and fiber converters. For proper operation, install it as a matched pair with the TEG-10GBS10D3 at the opposite end of the fiber link. The module includes a lifetime warranty.
