The Triton Vape is designed to detect nicotine and various environmental anomalies. With real-time cloud-based alerts. The Triton Pro is equipped with scalable integration options and boasts robust durability, backed by a 10-year warranty for long-term dependability.
Triton Vape Detector, Focused Single-Detection Capability for Vaping, Privacy-Compliant Design, Standalone Operation. Designed for environments requiring targeted vape detection with affordability and simplicity in mind. Detection coverage up to 15m. Optimized for high-accuracy vape detection to address vaping in schools, workplaces, and public spaces.Features: Real-time detection with customizable alerts for vape incidents. Integrated with the WAVE/Triton dashboard for monitoring and management. Operating temperature: 0°C to +40°C (32°F ~ 104°F). Power: 12VDC or PoE (802.3af).
Device Key Features:
- Operating Temperature: 0°C~+40°C (32°F~+104°F) / 0~90% RH (Non-Condensing)
- Weight: 340g
- Color: White
- Material: PC (Polycarbonate)
- Dimensions: 5.24” x 1.81” (133.10mm x 46.0mm)
- Max Load: 15kg
- Certifi cation: CE, FCC, IK8, RoHS, UKCA
Device Key Characteristics:
- Vaping
- False-Positive Rejection
- Air Quality
- Tamper Detection
- VMS Integrations
GENERAL
| Operating Temperature / Humidity | 32°F~+104°F (0°C~+40°C) / 0~90% RH (Non-Condensing) |
| Mounting Options | Surface Mount (recommended), Wall Mount via Stud, Pole Mount (optional). Conduit Adapter (optional). |
| Power Supply | POE (IEEE 802.3at Class 3 Compliance) 9w 48V |
| Certification | FCC, CE, RoHS, IK8, UKCA |
NETWORK
| Ethernet | RJ-45 (10/100 Base-T) |
COMMUNICATION I/O
| Triton Cloud | Cloud & App Software that extends the abilities of Triton hardware |
| Sent via AWS API | |
| SMS Text Message | Sent via Twilio API |
| Integrations | Vape Sensor integrates with many 3rd party VMS, communications, and safety systems. Most popular include: Hanwha WAVE, Milestone, Genetec, Raptor Technologies, i-Pro Video Insight, Axis D4100, Arcules, OpenEye, ExacqVision, DW Spectrum, Nx Witness, Ganz CORTROL, VAST 2, EPIC System, IC Realtime, and Avigilon. Contact Triton for integration requests and a full list of integrations. |
| Vaping | Detection of vaped and burn nicotine, THC, and other substances. Does not differentiate substances. |
| False-Positive Rejection | Rejects most aerosols with a similiar profile to vape / smoking (see masking detection). |
| Tamper Detection | Device Vandalism, Device Disconnect |
| Air Quality | Monitoring (sensor data updated every 15 minutes) of Temperature, Humidity, PMI and VOC. |
